Order No.: 5EA40RB01

Article sensor
Product name SITECO Connect Wireless
Protection rating IP66
Weight 0.8kg

SITECO Connect WirelessMast Box Motion Radar, sensor, communication: 2.4GHz, local mesh radio network, DALI, control: local setting and operation with USB stick, by movement, sensor technology: 2 radar movement sensors, automatic adjustment of the DALI dimming curve, optionally adjustable manually, controls one DALI ECG individually or up to 9 DALI ECGs via broadcast, installation type: surface-mounted, installation location: to mast, of plastic, voltage: 230V, voltage type: AC, cable length: 5 m, radar movement sensor, protection rating (complete): IP66, certification: CE, packaging unit: 1 piece, metal fastening straps not included in delivery

Downloads

Technical product information
Data for applications

Product details


Key data

System family SITECO Connect 31 Wireless
Product type sensor
Product name SITECO Connect Wireless
Order No. 5EA40RB01


Control


Certificates, Standards

Protection rating IP66
Temperature range (operation) -20..+60°C
Certification, designation CE


Material, Colour

housing plastic, transparent, colour-backed, dark grey


Mounting

Mounting method, mounting location surface-mounted, to mast
Mounting height 4..10m


Electrical connection

Connection cable, 4x 0.75mm², free wire ends
Nominal voltage 230V, AC


Dimensions, Weight

Weight 0.8kg


Inputs

radar movement sensor
Detection range max. 15x5m

System family
SITECO Connect 31 Wireless

Product type
sensor

Product name
SITECO Connect Wireless

Order No.
5EA40RB01

Protection rating
IP66

Temperature range (operation)
-20..+60°C

Certification, designation
CE

housing
plastic, transparent, colour-backed, dark grey

Mounting method, mounting location
surface-mounted, to mast

Mounting height
4..10m

Connection
cable, 4x 0.75mm², free wire ends

Nominal voltage
230V, AC

Weight
0.8kg

radar movement sensor

Detection range
max. 15x5m
