SITECO

spot

Family Product selection Configuration & data sheets

Product selection

Spot 11

Spot 11

Special features

Particularly high lumen package with outstanding energy efficiency
Two housing colours, two construction sizes
Can be preset to individual needs thanks to the multi-lumen function for various luminous flux packages
Lighting control via DALI-2 or as ON/OFF version available
Reflector can be replaced without tools if necessary and can therefore be adapted to changing requirements

Configuration & data sheets

Beam angle

Colour temperature

Light colour

UGR

Rated luminous flux (lm)

Control

Operating ambient temperature

Colour

Results

Spot 21 Performance, wide distribution, ON/OFF, Ø90, white

Order No.: 51SD147AW2B GTIN (EAN): 4058352678169
Colour temperatureColour renderingBeam angleLuminous fluxConnected loadLuminous efficacyControlDimension (mm)ColourWt. (kg)
CRI > 90wide distribution2800lm ON/OFFØ90white0.8
Show all details
Tender textData sheet (PDF, full)Complete download list

Spot 21 Performance, 45°, ON/OFF Multilumen, Ø90, traffic white (RAL 9016)

Order No.: 51SD14MAB5A GTIN (EAN): 4058352716359
Colour temperatureColour renderingBeam angleLuminous fluxConnected loadLuminous efficacyControlDimension (mm)ColourWt. (kg)
3000KCRI > 9045°5630lm38W148lm/WON/OFF MultilumenØ90traffic white (RAL 9016)0.8
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Spot 21 Performance, 45°, ON/OFF Multilumen, Ø90, traffic white (RAL 9016)

Order No.: 51SD14MAD5A GTIN (EAN): 4058352716366
Colour temperatureColour renderingBeam angleLuminous fluxConnected loadLuminous efficacyControlDimension (mm)ColourWt. (kg)
4000KCRI > 9045°5670lm38W149lm/WON/OFF MultilumenØ90traffic white (RAL 9016)0.8
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Spot 21 Performance, wide distribution, ON/OFF, Ø90, white

Order No.: 51SD147AW2BGTIN (EAN): 4058352678169

Colour temperature
Colour renderingCRI > 90
Beam anglewide distribution
Luminous flux2800lm
Connected load
Luminous efficacy
ControlON/OFF
Dimension (mm)Ø90
Colourwhite
Wt. (kg)0.8
Show all details

Spot 21 Performance, 45°, ON/OFF Multilumen, Ø90, traffic white (RAL 9016)

Order No.: 51SD14MAB5AGTIN (EAN): 4058352716359

Colour temperature3000K
Colour renderingCRI > 90
Beam angle45°
Luminous flux5630lm
Connected load38W
Luminous efficacy148lm/W
ControlON/OFF Multilumen
Dimension (mm)Ø90
Colourtraffic white (RAL 9016)
Wt. (kg)0.8
Show all details

Spot 21 Performance, 45°, ON/OFF Multilumen, Ø90, traffic white (RAL 9016)

Order No.: 51SD14MAD5AGTIN (EAN): 4058352716366

Colour temperature4000K
Colour renderingCRI > 90
Beam angle45°
Luminous flux5670lm
Connected load38W
Luminous efficacy149lm/W
ControlON/OFF Multilumen
Dimension (mm)Ø90
Colourtraffic white (RAL 9016)
Wt. (kg)0.8
Show all details
