SITECO Connect 11

Product typesConfiguration & data sheets

SITECO Connect for indoor use unlocks the full potential of your lighting system. Sensor-based control saves energy and extends luminaire service life through targeted dimming. In turn, increasing illuminance as needed creates greater visibility and safety when necessary. Lighting management systems automate control, create transparency, and optimize operations, allowing you to focus on what matters most.

SITECO Connect 11 controls lighting as needed via sensors, allows flexible groups and scenes, checks self-contained emergency luminaires, offers central monitoring and analysis, and can be seamlessly integrated into building management systems via standardized interfaces.

Product types

SITECO Connect 11

SITECO Connect 11

Intro product family

Key data

Article base package S/D; base package M/D; base package S/P; base package M/P; DALI-2 terminal; input terminal; output terminal; power measurement terminal; K-Bus coupler; expansion set; cabinet upgrade; Switch; expansion panel; LTE remote maintenance router
Equipment 1…15 DALI lines; 1…40 DALI lines; 1x Ethernet bus coupler, 1x bus end terminal, 1x installation set control; pre-assembled system distribution box with power supply and cable glands; touch panel PC; DIN rail PC

Special features

Controller available as DIN rail or touch panel PC
Different basic packages (max. 1…12 or 1…18 DALI lines) provide maximum flexibility
Future-proof: through open and standardized interfaces, such as DALI-2, BACnet, KNX
Easy commissioning: all function via commissioning software
Access: different user rights and roles provide functional security
Manual intervention: possible at any time by users
Future-proofing and flexibility: through individual addressing and grouping of luminaires and sensors
Cost efficiency: accelerating payback through sensors (daylight and motion)
Proactive: automatic control of lighting through intelligent time schedules
SITECO HCLlive: light influences our body visually, emotionally and biologically. It sets the pace for our internal clock
Everything in view: web visualization of the entire solution (license already included)
Status of the lighting system: visualization of sensor and luminaire faults
Energy consumption: visualization of the energy consumption of the lighting system possible
Energy consumption: measurement of energy consumption possible using calibrated measuring devices
Intelligence: intelligent control of luminaires depending on partition walls (e.g. sports halls, meeting rooms, etc.)
Remote maintenance: commissioning or analysis of the lighting system can also be carried out remotely if required

Configuration & data sheets

Lighting management

  • basic package M/D for controlling max. 40 DALI lines; including 1x DIN rail PC, 1x DALI-2 terminal, 1x power supply, 1x fuse, 1x license pre-installed
  • basic package S/D for controlling max. 15 DALI lines; including 1x DIN rail PC, 1x DALI-2 terminal, 1x power supply, 1x fuse, 1x license pre-installed
  • basic package S/P for controlling max. 15 DALI lines; including 1x touch panel PC, 1x DALI-2 terminal, 1x power supply, 1x fuse, 1x license pre-installed
  • basic package M/P for controlling max. 40 DALI lines; including 1x touch panel PC, 1x DALI-2 terminal, 1x power supply, 1x fuse, 1x license pre-installed
  • per DALI terminal: max. 250mA power supply
  • per DALI terminal: max. 64 ECG and 64 sensor addresses
  • DALI-2 terminal: DALI-2 certified according to parts 101, 103, 303 and 304
  • input terminal: for recording max. 8 binary control signals
  • output terminal: for switching max. 8 actuators
  • power measurement terminal: for connecting external current transformers
  • extension set: extension to the basic package for each additional sub-distribution. Set consisting of 1x power supply, 1x fuse, 1x bus coupler, 1x end terminal
  • control cabinet upgrade: prefabricated system distributor with power supply and screw connections, fully installed and wired; in combination with a touch panel PC, this is installed in the control cabinet door; only in combination with basic packages
  • compatible DALI-2 sensors and DALI-2 push button couplers see "SITECO Connect DALI-2 components"

Results

base package S/P

Order No.: 5LZ930101 GTIN (EAN): 4058352385913
EquipmentControlInstallation locationWt. (kg)
1..15 DALI lines, touch panel PCDALI 2in an electrical distributor0.9
Show all details
Tender textData sheet (PDF, full)Complete download list

base package M/P

Order No.: 5LZ930103 GTIN (EAN): 4058352385937
EquipmentControlInstallation locationWt. (kg)
1..40 DALI lines, touch panel PCDALI 2in an electrical distributor0.9
Show all details
Tender textData sheet (PDF, full)Complete download list

base package S/D

Order No.: 5LZ930100 GTIN (EAN): 4058352385906
EquipmentControlInstallation locationWt. (kg)
1..15 DALI lines, DIN rail PCDALI 2in an electrical distributor0.6
Show all details
Tender textData sheet (PDF, full)Complete download list

base package M/D

Order No.: 5LZ930102 GTIN (EAN): 4058352385920
EquipmentControlInstallation locationWt. (kg)
1..40 DALI lines, DIN rail PCDALI 2in an electrical distributor0.6
Show all details
Tender textData sheet (PDF, full)Complete download list

LTE remote maintenance router

Order No.: 5LZ930REM1 GTIN (EAN): 4069025335197
EquipmentControlInstallation locationWt. (kg)
in an electrical distributor0.1
Show all details
Tender textData sheet (PDF, full)Complete download list

DALI-2 terminal

Order No.: 5LZ930200 GTIN (EAN): 4058352385944
EquipmentControlInstallation locationWt. (kg)
DALI 2in an electrical distributor0.1
Show all details
Tender textData sheet (PDF, full)Complete download list

input terminal

Order No.: 5LZ930201 GTIN (EAN): 4058352385951
EquipmentControlInstallation locationWt. (kg)
in an electrical distributor0.1
Show all details
Tender textData sheet (PDF, full)Complete download list

output terminal

Order No.: 5LZ930202 GTIN (EAN): 4058352385968
EquipmentControlInstallation locationWt. (kg)
in an electrical distributor0.1
Show all details
Tender textData sheet (PDF, full)Complete download list

power measurement terminal

Order No.: 5LZ930203 GTIN (EAN): 4058352386682
EquipmentControlInstallation locationWt. (kg)
in an electrical distributor0.1
Show all details
Tender textData sheet (PDF, full)Complete download list

K-Bus coupler

Order No.: 5LZ930206 GTIN (EAN): 4058352385999
EquipmentControlInstallation locationWt. (kg)
in an electrical distributor0.1
Show all details
Tender textData sheet (PDF, full)Complete download list

expansion set

Order No.: 5LZ930300 GTIN (EAN): 4058352386002
EquipmentControlInstallation locationWt. (kg)
1x Ethernet bus coupler, 1x bus end terminal, 1x installation set control in an electrical distributor0.1
Show all details
Tender textData sheet (PDF, full)Complete download list

cabinet upgrade

Order No.: 5LZ930301 GTIN (EAN): 4058352386019
EquipmentControlInstallation locationWt. (kg)
pre-assembled system distribution box with power supply and cable glands 0.1
Show all details
Tender textData sheet (PDF, full)Complete download list

Switch

Order No.: 5LZ930302 GTIN (EAN): 4058352386026
EquipmentControlInstallation locationWt. (kg)
in an electrical distributor0.3
Show all details
Tender textData sheet (PDF, full)Complete download list

expansion panel

Order No.: 5LZ930304 GTIN (EAN): 4058352386040
EquipmentControlInstallation locationWt. (kg)
touch panel PC in a switching cabinet0.9
Show all details
Tender textData sheet (PDF, full)Complete download list

base package S/P

Order No.: 5LZ930101GTIN (EAN): 4058352385913

Equipment1..15 DALI lines, touch panel PC
ControlDALI 2
Installation locationin an electrical distributor
Wt. (kg)0.9
Show all details

base package M/P

Order No.: 5LZ930103GTIN (EAN): 4058352385937

Equipment1..40 DALI lines, touch panel PC
ControlDALI 2
Installation locationin an electrical distributor
Wt. (kg)0.9
Show all details

base package S/D

Order No.: 5LZ930100GTIN (EAN): 4058352385906

Equipment1..15 DALI lines, DIN rail PC
ControlDALI 2
Installation locationin an electrical distributor
Wt. (kg)0.6
Show all details

base package M/D

Order No.: 5LZ930102GTIN (EAN): 4058352385920

Equipment1..40 DALI lines, DIN rail PC
ControlDALI 2
Installation locationin an electrical distributor
Wt. (kg)0.6
Show all details

LTE remote maintenance router

Order No.: 5LZ930REM1GTIN (EAN): 4069025335197

Equipment
Control
Installation locationin an electrical distributor
Wt. (kg)0.1
Show all details

DALI-2 terminal

Order No.: 5LZ930200GTIN (EAN): 4058352385944

Equipment
ControlDALI 2
Installation locationin an electrical distributor
Wt. (kg)0.1
Show all details

input terminal

Order No.: 5LZ930201GTIN (EAN): 4058352385951

Equipment
Control
Installation locationin an electrical distributor
Wt. (kg)0.1
Show all details

output terminal

Order No.: 5LZ930202GTIN (EAN): 4058352385968

Equipment
Control
Installation locationin an electrical distributor
Wt. (kg)0.1
Show all details

power measurement terminal

Order No.: 5LZ930203GTIN (EAN): 4058352386682

Equipment
Control
Installation locationin an electrical distributor
Wt. (kg)0.1
Show all details

K-Bus coupler

Order No.: 5LZ930206GTIN (EAN): 4058352385999

Equipment
Control
Installation locationin an electrical distributor
Wt. (kg)0.1
Show all details

expansion set

Order No.: 5LZ930300GTIN (EAN): 4058352386002

Equipment1x Ethernet bus coupler, 1x bus end terminal, 1x installation set control
Control
Installation locationin an electrical distributor
Wt. (kg)0.1
Show all details

cabinet upgrade

Order No.: 5LZ930301GTIN (EAN): 4058352386019

Equipmentpre-assembled system distribution box with power supply and cable glands
Control
Installation location
Wt. (kg)0.1
Show all details

Switch

Order No.: 5LZ930302GTIN (EAN): 4058352386026

Equipment
Control
Installation locationin an electrical distributor
Wt. (kg)0.3
Show all details

expansion panel

Order No.: 5LZ930304GTIN (EAN): 4058352386040

Equipmenttouch panel PC
Control
Installation locationin a switching cabinet
Wt. (kg)0.9
Show all details
