SITECO
Trunking Flex
Trunking Flex 31 refurbishment luminaire insert with through-wiring
Key data
Article luminaire insert
Protection rating IP20
Colour temperature 4000K
Lighting effect direct wide distribution
Special features
Simple refurbishment of all standard continuous-row trunking systems: Always suitable and secure thanks to solid universal spring catch with automatic earthing of the existing track
Maximum cost-effectiveness: rapid amortisation thanks to simple refurbishment and luminous efficacy > 180lm/W
Refurbishment independent of the wiring of the existing system: thanks to integrated through-wiring
Flexible in use: with optimised light distribution and multi-lumen function
Can be integrated into modern lighting control systems: through DALI-2 versions
Eligible: fulfils all requirements for BEG funding
Links
Configuration & data sheets
- Multilumen on/off ECG with six luminous flux levels
- housing overhang (20mm) at the joints
Results
Trunking Flex 31, wide distribution, IP20, AC, with Through-wiring 7x 2.5mm²
Order No.: 51RF12DB49XG5007 GTIN (EAN): 4069025487803
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 9000 | 49W | 182lm/W | DALI 2 | -25..+45°C | IP20 | 1475 | 1.6 |
Trunking Flex 31, wide distribution, IP20, AC, with Through-wiring 7x 2.5mm²
Order No.: 51RF12MB49XG5007 GTIN (EAN): 4069025487827
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 9100 | 51W | 180lm/W | ON/OFF Multilumen | -25..+45°C | IP20 | 1475 | 1.9 |
Trunking Flex 31, wide distribution, IP20, AC, with Through-wiring 7x 2.5mm²
Order No.: 51RF12DB49XG5007GTIN (EAN): 4069025487803
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 9000 |
| Connected load | 49W |
| Luminous efficacy | 182lm/W |
| Control | DALI 2 |
| ta | -25..+45°C |
| Protection rating | IP20 |
| L (mm) | 1475 |
| Wt. (kg) | 1.6 |
Trunking Flex 31, wide distribution, IP20, AC, with Through-wiring 7x 2.5mm²
Order No.: 51RF12MB49XG5007GTIN (EAN): 4069025487827
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 9100 |
| Connected load | 51W |
| Luminous efficacy | 180lm/W |
| Control | ON/OFF Multilumen |
| ta | -25..+45°C |
| Protection rating | IP20 |
| L (mm) | 1475 |
| Wt. (kg) | 1.9 |
Optional accessories
| Order No.: 59RT007GTIN (EAN): 4058352765173 | Show all details |
| Order No.: 59RF1FNKGTIN (EAN): 4069025327550 | Show all details |
| Order No.: 59RF1FTKGTIN (EAN): 4069025327604 | Show all details |
| Order No.: 59RE10AGTIN (EAN): 4058352777169 | Show all details |
| Order No.: 59RE10BGTIN (EAN): 4058352777183 | Show all details |
| Order No.: 59RF1FNKF7GTIN (EAN): 4069025637376 | Show all details |
