SiCompact® 31

ProducttypesConfiguration & Datasheets

SiCompact® stands for high reliability, robustness, ease of assembly and quality. High-quality workmanship, modern lighting technology and the high degree of protection IP66 make the floodlight family the first choice for standard outdoor lighting tasks and present it as an economical, low-maintenance, energy-efficient lighting solution.

Industrial-look design meets state of the art technology

SiCompact® 31 mini

Intro to Productfamily

Data

Article floodlight
Lighting effect direct asymmetric distribution
Net luminous flux 7700lm to 20000lm
Colour temperature 3000K; 4000K
Control ON/OFF

Specials

Easy and quick installation thanks to mounting bracket and preassembled connection cable (2m)
High efficient operation with up to 170lm/W and asymmetric narrow light distribution (PL32)
Robust housing and ESD-protected LED module, IP66, IK08, dustproof, vibration stability tested with 250,000 strokes, ENEC certified
High flexibility for all requirements with four construction sizes and rated luminous fluxes of 4,400–70,000lm

Configuration & Datasheets

Results

SiCompact® 31 mini, PL32, asymmetric distribution

Order No.: 5XA7571B1K23GTIN (EAN): 4058352624586
Colour temperatureColour renderingLuminous fluxLight distributionConnected loadLuminous efficacyControlWt. (kg)
3000KCRI > 708000lmPL3248W167lm/WON/OFF5.8

SiCompact® 31 mini, PL32, asymmetric distribution

Order No.: 5XA7571C1K23GTIN (EAN): 4058352624623
Colour temperatureColour renderingLuminous fluxLight distributionConnected loadLuminous efficacyControlWt. (kg)
3000KCRI > 7015000lmPL32100W150lm/WON/OFF5.6

SiCompact® 31 mini, PL32, asymmetric distribution

Order No.: 5XA7571F1K23GTIN (EAN): 4058352633564
Colour temperatureColour renderingLuminous fluxLight distributionConnected loadLuminous efficacyControlWt. (kg)
3000KCRI > 7020000lmPL32130W154lm/WON/OFF5.8

SiCompact® 31 mini, PL32, asymmetric distribution

Order No.: 5XA7571C2K23GTIN (EAN): 4058352624647
Colour temperatureColour renderingLuminous fluxLight distributionConnected loadLuminous efficacyControlWt. (kg)
4000KCRI > 7015000lmPL3295W158lm/WON/OFF5.6

SiCompact® 31 mini, PL32, asymmetric distribution

Order No.: 5XA7571B2K22GTIN (EAN): 4058352361528
Colour temperatureColour renderingLuminous fluxLight distributionConnected loadLuminous efficacyControlWt. (kg)
4000KCRI > 707700lmPL3265W118lm/WON/OFF5.8

SiCompact® 31 mini, PL32, asymmetric distribution

Order No.: 5XA7571B1K23GTIN (EAN): 4058352624586

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux8000lm
Light distributionPL32
Connected load48W
Luminous efficacy167lm/W
ControlON/OFF
Wt. (kg)5.8

SiCompact® 31 mini, PL32, asymmetric distribution

Order No.: 5XA7571C1K23GTIN (EAN): 4058352624623

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux15000lm
Light distributionPL32
Connected load100W
Luminous efficacy150lm/W
ControlON/OFF
Wt. (kg)5.6

SiCompact® 31 mini, PL32, asymmetric distribution

Order No.: 5XA7571F1K23GTIN (EAN): 4058352633564

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux20000lm
Light distributionPL32
Connected load130W
Luminous efficacy154lm/W
ControlON/OFF
Wt. (kg)5.8

SiCompact® 31 mini, PL32, asymmetric distribution

Order No.: 5XA7571C2K23GTIN (EAN): 4058352624647

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux15000lm
Light distributionPL32
Connected load95W
Luminous efficacy158lm/W
ControlON/OFF
Wt. (kg)5.6

SiCompact® 31 mini, PL32, asymmetric distribution

Order No.: 5XA7571B2K22GTIN (EAN): 4058352361528

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux7700lm
Light distributionPL32
Connected load65W
Luminous efficacy118lm/W
ControlON/OFF
Wt. (kg)5.8

Optional accessory

Articlesystem connector: plug/socket, IP65, 3-pole, max. 2.5mm²PU1 pc.Wt. (kg)0.1Order No.: 5NX30003GTIN (EAN): 4058352143254Show details
Articlecross-arm, single, galvanised, d_a= 60mmPU1 pc.Wt. (kg)2.0Order No.: 5NY74701XA01GTIN (EAN): 4039806199508Show details
Articlecross-arm, single, galvanised, d_a= 76mmPU1 pc.Wt. (kg)2.2Order No.: 5NY74701XA11GTIN (EAN): 4039806199522Show details
Articlecross-arm, single, galvanised, d_a= 89mmPU1 pc.Wt. (kg)2.3Order No.: 5NY74701XA21GTIN (EAN): 4039806199546Show details
Articlecross-arm, twin, galvanised, d_a= 76mmPU1 pc.Wt. (kg)3.3Order No.: 5NY74702XA11GTIN (EAN): 4039806199409Show details
Articlecross-arm, twin, galvanised, d_a= 89mmPU1 pc.Wt. (kg)3.5Order No.: 5NY74702XA21GTIN (EAN): 4039806383365Show details
Articlecross-arm, single, DB 702S, d_a= 60mmPU1 pc.Wt. (kg)2.0Order No.: 5NY74701XA0108GTIN (EAN): 4050737956084Show details
Articlecross-arm, single, DB 702S, d_a= 76mmPU1 pc.Wt. (kg)2.2Order No.: 5NY74701XA1108GTIN (EAN): 4050737956107Show details
Articlecross-arm, single, DB 702S, d_a= 89mmPU1 pc.Wt. (kg)2.3Order No.: 5NY74701XA2108GTIN (EAN): 4050737956138Show details
Articlecross-arm, twin, DB 702S, d_a= 76mmPU1 pc.Wt. (kg)3.2Order No.: 5NY74702XA1108GTIN (EAN): 4050737956169Show details
