SiCompact® 31

ProducttypesConfiguration & Datasheets

SiCompact® stands for high reliability, robustness, ease of assembly and quality. High-quality workmanship, modern lighting technology and the high degree of protection IP66 make the floodlight family the first choice for standard outdoor lighting tasks and present it as an economical, low-maintenance, energy-efficient lighting solution.

Industrial-look design meets state of the art technology

SiCompact® 31 midi

Intro to Productfamily

Data

Article floodlight
Lighting effect direct asymmetric distribution
Net luminous flux 23800lm to 37000lm
Colour temperature 3000K; 4000K
Control ON/OFF

Specials

Easy and quick installation thanks to mounting bracket and preassembled connection cable (2m)
High efficient operation with up to 170lm/W and asymmetric narrow light distribution (PL32)
Robust housing and ESD-protected LED module, IP66, IK08, dustproof, vibration stability tested with 250,000 strokes, ENEC certified
High flexibility for all requirements with four construction sizes and rated luminous fluxes of 4,400–70,000lm

Configuration & Datasheets

Results

SiCompact® 31 midi, PL32, asymmetric distribution

Order No.: 5XA7581D1K23GTIN (EAN): 4058352624678
Colour temperatureColour renderingLuminous fluxLight distributionConnected loadLuminous efficacyControlWt. (kg)
3000KCRI > 7027000lmPL32171W158lm/WON/OFF8.5

SiCompact® 31 midi, PL32, asymmetric distribution

Order No.: 5XA7581E1K23GTIN (EAN): 4058352624708
Colour temperatureColour renderingLuminous fluxLight distributionConnected loadLuminous efficacyControlWt. (kg)
3000KCRI > 7037000lmPL32250W148lm/WON/OFF8.5

SiCompact® 31 midi, PL32, asymmetric distribution

Order No.: 5XA7581E2K23GTIN (EAN): 4058352624722
Colour temperatureColour renderingLuminous fluxLight distributionConnected loadLuminous efficacyControlWt. (kg)
4000KCRI > 7037000lmPL32243W152lm/WON/OFF8.5

SiCompact® 31 midi, PL32, asymmetric distribution

Order No.: 5XA7581D2K22GTIN (EAN): 4058352361542
Colour temperatureColour renderingLuminous fluxLight distributionConnected loadLuminous efficacyControlWt. (kg)
4000KCRI > 7023800lmPL32200W119lm/WON/OFF9.6

SiCompact® 31 midi, PL32, asymmetric distribution

Order No.: 5XA7581D1K23GTIN (EAN): 4058352624678

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux27000lm
Light distributionPL32
Connected load171W
Luminous efficacy158lm/W
ControlON/OFF
Wt. (kg)8.5

SiCompact® 31 midi, PL32, asymmetric distribution

Order No.: 5XA7581E1K23GTIN (EAN): 4058352624708

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux37000lm
Light distributionPL32
Connected load250W
Luminous efficacy148lm/W
ControlON/OFF
Wt. (kg)8.5

SiCompact® 31 midi, PL32, asymmetric distribution

Order No.: 5XA7581E2K23GTIN (EAN): 4058352624722

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux37000lm
Light distributionPL32
Connected load243W
Luminous efficacy152lm/W
ControlON/OFF
Wt. (kg)8.5

SiCompact® 31 midi, PL32, asymmetric distribution

Order No.: 5XA7581D2K22GTIN (EAN): 4058352361542

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux23800lm
Light distributionPL32
Connected load200W
Luminous efficacy119lm/W
ControlON/OFF
Wt. (kg)9.6

Optional accessory

Articlesystem connector: plug/socket, IP65, 3-pole, max. 2.5mm²PU1 pc.Wt. (kg)0.1Order No.: 5NX30003GTIN (EAN): 4058352143254Show details
Articlecross-arm, single, galvanised, d_a= 76mmPU1 pc.Wt. (kg)2.2Order No.: 5NY74701XA11GTIN (EAN): 4039806199522Show details
Articlecross-arm, single, galvanised, d_a= 89mmPU1 pc.Wt. (kg)2.3Order No.: 5NY74701XA21GTIN (EAN): 4039806199546Show details
Articlecross-arm, twin, galvanised, d_a= 76mmPU1 pc.Wt. (kg)4.4Order No.: 5NY74802XA11GTIN (EAN): 4039806199447Show details
Articlecross-arm, twin, galvanised, d_a= 89mmPU1 pc.Wt. (kg)4.5Order No.: 5NY74802XA21GTIN (EAN): 4039806199454Show details
Articlecross-arm, single, DB 702S, d_a= 76mmPU1 pc.Wt. (kg)2.2Order No.: 5NY74701XA1108GTIN (EAN): 4050737956107Show details
Articlecross-arm, single, DB 702S, d_a= 89mmPU1 pc.Wt. (kg)2.3Order No.: 5NY74701XA2108GTIN (EAN): 4050737956138Show details
Articlecross-arm, twin, DB 702S, d_a= 76mmPU1 pc.Wt. (kg)4.2Order No.: 5NY74802XA1108GTIN (EAN): 4050737956183Show details
Articlecross-arm, twin, DB 702S, d_a= 89mmPU1 pc.Wt. (kg)4.5Order No.: 5NY74802XA2108GTIN (EAN): 4050737956206Show details
