SITECO

Vega

Application Configuration & data sheets

Vega 11 to mounting rail

Key data

Article office luminaire
Lighting effect direct/indirect symmetric distribution
Net luminous flux 4300lm to 8130lm
Colour temperature 3000K; 4000K
Control DALI

Special features

Purist look with an almost transparent design: height of prismatic plate only 6mm, height of luminaire housing only 43mm
Outstanding lighting technology for very uniform light distribution with direct/indirect component for pleasant room atmosphere and good colour rendering (CRI ≥ 80)
High flexibility due to versions with DALI, with/without sensor technology, 3000K/4000K, 3 mounting options (pendant, surface-mounted, system rail)
High quality appearance due to special vaporisation of the prismatic plate at the edges, aluminum housing and decorative specular strip

Configuration & data sheets

Colour temperature

Rated luminous flux (lm)

Operating ambient temperature

Installation type

  • luminaire incl. pre-assembled connection cable, l = 1.5m
  • luminaire suitable for suspended mounting as single luminaire or for fixing to Vega® mounting rail; please order mounting accessories separately to match the desired type of installation
  • for installation on the mounting rail: please order fixing accessories for the luminaire on the rail and specific suspension accessories for the mounting rail separately
  • luminaire with direct/indirect (62:38) distribution as standard; please order baffle for 100% direct light distribution or baffle for light distribution with higher direct component (70:30) separately if required
  • for luminaires with integrated sensors: local control without a higher-level lighting or building management system, daylight- and occupancy-dependent control with fully automatic operation. Commissioning with service remote control 5LZ904307

Results

Vega 11, direct/indirect distribution, DALI

Order No.: 5MN238DLC GTIN (EAN): 4050737963761
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlWt. (kg)
4000KCRI > 804300lm31W139lm/WDALI6.5
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Vega 11, direct/indirect distribution, DALI

Order No.: 5MN238DLC003 GTIN (EAN): 4050737964164
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlWt. (kg)
3000KCRI > 804300lm35W123lm/WDALI6.5
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Vega 11, direct/indirect distribution, DALI

Order No.: 5MN238DLC0S GTIN (EAN): 4050737964041
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlWt. (kg)
4000KCRI > 804300lm31W139lm/WDALI6.6
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Vega 11, direct/indirect distribution, DALI

Order No.: 5MN238DLE GTIN (EAN): 4050737964188
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlWt. (kg)
4000KCRI > 808130lm62W131lm/WDALI7.2
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Vega 11, direct/indirect distribution, DALI

Order No.: 5MN238DLE003 GTIN (EAN): 4050737963846
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlWt. (kg)
3000KCRI > 807300lm62W118lm/WDALI6.5
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Vega 11, direct/indirect distribution, DALI

Order No.: 5MN238DLE0S GTIN (EAN): 4050737963747
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlWt. (kg)
4000KCRI > 808130lm62W131lm/WDALI6.6
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Vega 11, direct/indirect distribution, DALI

Order No.: 5MN238DLE0S3 GTIN (EAN): 4050737964263
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlWt. (kg)
3000KCRI > 807300lm62W118lm/WDALI6.6
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Vega 11, direct/indirect distribution, DALI

Order No.: 5MN238DLCGTIN (EAN): 4050737963761

Colour temperature4000K
Colour renderingCRI > 80
Luminous flux4300lm
Connected load31W
Luminous efficacy139lm/W
ControlDALI
Wt. (kg)6.5
Show all details

Vega 11, direct/indirect distribution, DALI

Order No.: 5MN238DLC003GTIN (EAN): 4050737964164

Colour temperature3000K
Colour renderingCRI > 80
Luminous flux4300lm
Connected load35W
Luminous efficacy123lm/W
ControlDALI
Wt. (kg)6.5
Show all details

Vega 11, direct/indirect distribution, DALI

Order No.: 5MN238DLC0SGTIN (EAN): 4050737964041

Colour temperature4000K
Colour renderingCRI > 80
Luminous flux4300lm
Connected load31W
Luminous efficacy139lm/W
ControlDALI
Wt. (kg)6.6
Show all details

Vega 11, direct/indirect distribution, DALI

Order No.: 5MN238DLEGTIN (EAN): 4050737964188

Colour temperature4000K
Colour renderingCRI > 80
Luminous flux8130lm
Connected load62W
Luminous efficacy131lm/W
ControlDALI
Wt. (kg)7.2
Show all details

Vega 11, direct/indirect distribution, DALI

Order No.: 5MN238DLE003GTIN (EAN): 4050737963846

Colour temperature3000K
Colour renderingCRI > 80
Luminous flux7300lm
Connected load62W
Luminous efficacy118lm/W
ControlDALI
Wt. (kg)6.5
Show all details

Vega 11, direct/indirect distribution, DALI

Order No.: 5MN238DLE0SGTIN (EAN): 4050737963747

Colour temperature4000K
Colour renderingCRI > 80
Luminous flux8130lm
Connected load62W
Luminous efficacy131lm/W
ControlDALI
Wt. (kg)6.6
Show all details

Vega 11, direct/indirect distribution, DALI

Order No.: 5MN238DLE0S3GTIN (EAN): 4050737964263

Colour temperature3000K
Colour renderingCRI > 80
Luminous flux7300lm
Connected load62W
Luminous efficacy118lm/W
ControlDALI
Wt. (kg)6.6
Show all details

Mandatory accessories

Articlemounting rail, for suspended mounting, L= 4000mmPU1 pc.Wt. (kg)4.5Order No.: 5MN91004GTIN (EAN): 4050737762609Show all details
Articleend cap for rail, light grey (RAL 7035)PU2 pcs.Wt. (kg)0.1Order No.: 5MN91005GTIN (EAN): 4050737716947Show all details
Articleconnector, for mounting railPU1 pc.Wt. (kg)0.1Order No.: 5MN91002GTIN (EAN): 4050737726984Show all details
Articlemounting set, for luminaire, for surface-mounted to the mounting railPU4 pcs.Wt. (kg)0.3Order No.: 5MN91006GTIN (EAN): 4050737709109Show all details
Articlewire suspension with ceiling canopy, grey, round, suspension height up to 1.2mPU1 pc.Wt. (kg)0.1Order No.: 5MN91101GTIN (EAN): 4050737709123Show all details
Articlewire suspension with ceiling canopy, white, round, suspension height up to 1.2mPU1 pc.Wt. (kg)0.1Order No.: 5MN91102GTIN (EAN): 4050737709130Show all details
Articlewire suspension with ceiling canopy, grey, angular, suspension height up to 1.2mPU1 pc.Wt. (kg)0.5Order No.: 5MN91103GTIN (EAN): 4050737709154Show all details
Articlewire suspension with ceiling canopy, white, angular, suspension height up to 1.2mPU1 pc.Wt. (kg)0.1Order No.: 5MN91104GTIN (EAN): 4050737709178Show all details
Articlewire suspension with ceiling sleeve, suspension height up to 1.2mPU1 pc.Wt. (kg)0.1Order No.: 5MN91301GTIN (EAN): 4050737709192Show all details
Articleservice remote controlPU1 pc.Wt. (kg)0.2Order No.: 5LZ904307GTIN (EAN): 4052899195967Show all details

Optional accessories

Articlepassepartout, for luminaire, direct/indirect distribution, 70:30PU1 pc.Wt. (kg)0.5Order No.: 5MN91402GTIN (EAN): 4050737755007Show all details
