SITECO
spot
Family
Spot 21 Performance Performance. Uniform family design meets outstanding lighting technology with maximum efficiency (163lm/W) and service life (100,000 hours)
Spot 21 Standard Standard. Proven technology for standard applications with high efficiency (153lm/W) and service life (50,000 hours)
Spot 31 Basic. Practical, efficient (126lm/W) and durable (50,000 hours)
Spot 21 for Licross
Spot 21 for Modario
Spot 21 for Modario
Special features
Compact construction size in three housing colours
Can be preset to individual needs thanks to the multi-lumen function for various luminous flux packages
Reflector can be replaced without tools if necessary and can therefore be adapted to changing requirements
Links
Configuration & data sheets
Results
Delivery time on request
Spot 21, medium distribution, ON/OFF Multilumen, Ø90, traffic white (RAL 9016)
Order No.: 51SM13MB11A2C GTIN (EAN): 4069025531308
| Colour temperature | Colour rendering | Beam angle | Luminous flux | Connected load | Luminous efficacy | Control | Dimension (mm) | Colour | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|
| 2700K | CRI > 90 | medium distribution | 3860lm | 29W | 130lm/W | ON/OFF Multilumen | Ø90 | traffic white (RAL 9016) | 1.4 |
Delivery time on request
Spot 21, medium distribution, ON/OFF Multilumen, Ø90, traffic white (RAL 9016)
Order No.: 51SM13MB11B2C GTIN (EAN): 4069025531353
| Colour temperature | Colour rendering | Beam angle | Luminous flux | Connected load | Luminous efficacy | Control | Dimension (mm) | Colour | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|
| 3000K | CRI > 90 | medium distribution | 3910lm | 29W | 130lm/W | ON/OFF Multilumen | Ø90 | traffic white (RAL 9016) | 1.4 |
Delivery time on request
Spot 21, medium distribution, ON/OFF Multilumen, Ø90, traffic white (RAL 9016)
Order No.: 51SM13MB11D2C GTIN (EAN): 4069025531360
| Colour temperature | Colour rendering | Beam angle | Luminous flux | Connected load | Luminous efficacy | Control | Dimension (mm) | Colour | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 90 | medium distribution | 4050lm | 29W | 130lm/W | ON/OFF Multilumen | Ø90 | traffic white (RAL 9016) | 1.4 |
Delivery time on request
Spot 21, medium distribution, DALI 2, Multilumen, Ø90, traffic white (RAL 9016)
Order No.: 51SM13DB11D2C GTIN (EAN): 4069025531278
| Colour temperature | Colour rendering | Beam angle | Luminous flux | Connected load | Luminous efficacy | Control | Dimension (mm) | Colour | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 90 | medium distribution | 4170lm | 31W | 130lm/W | DALI 2, Multilumen | Ø90 | traffic white (RAL 9016) | 1.4 |
Delivery time on request
Spot 21, wide distribution, ON/OFF Multilumen, Ø90, traffic white (RAL 9016)
Order No.: 51SM14MB11A2C GTIN (EAN): 4069025531483
| Colour temperature | Colour rendering | Beam angle | Luminous flux | Connected load | Luminous efficacy | Control | Dimension (mm) | Colour | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|
| 2700K | CRI > 90 | wide distribution | 3860lm | 29W | 130lm/W | ON/OFF Multilumen | Ø90 | traffic white (RAL 9016) | 1.4 |
Delivery time on request
Spot 21, wide distribution, ON/OFF Multilumen, Ø90, traffic white (RAL 9016)
Order No.: 51SM14MB11B2C GTIN (EAN): 4069025531537
| Colour temperature | Colour rendering | Beam angle | Luminous flux | Connected load | Luminous efficacy | Control | Dimension (mm) | Colour | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|
| 3000K | CRI > 90 | wide distribution | 3910lm | 29W | 130lm/W | ON/OFF Multilumen | Ø90 | traffic white (RAL 9016) | 1.4 |
Delivery time on request
Spot 21, wide distribution, ON/OFF Multilumen, Ø90, traffic white (RAL 9016)
Order No.: 51SM14MB11D2C GTIN (EAN): 4069025531544
| Colour temperature | Colour rendering | Beam angle | Luminous flux | Connected load | Luminous efficacy | Control | Dimension (mm) | Colour | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 90 | wide distribution | 4050lm | 29W | 130lm/W | ON/OFF Multilumen | Ø90 | traffic white (RAL 9016) | 1.4 |
Delivery time on request
Spot 21, wide distribution, DALI, Ø90, traffic white (RAL 9016)
Order No.: 51SM14DB11D2C GTIN (EAN): 4069025531452
| Colour temperature | Colour rendering | Beam angle | Luminous flux | Connected load | Luminous efficacy | Control | Dimension (mm) | Colour | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 90 | wide distribution | 4170lm | 31W | 130lm/W | DALI | Ø90 | traffic white (RAL 9016) | 1.4 |
Delivery time on request
Spot 21, medium distribution, DALI 2, Multilumen, Ø90, traffic white (RAL 9016)
Order No.: 51SM13DB11A2C GTIN (EAN): 4069025531216
| Colour temperature | Colour rendering | Beam angle | Luminous flux | Connected load | Luminous efficacy | Control | Dimension (mm) | Colour | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|
| 2700K | CRI > 90 | medium distribution | 3800lm | 31W | 130lm/W | DALI 2, Multilumen | Ø90 | traffic white (RAL 9016) | 1.4 |
Delivery time on request
Spot 21, medium distribution, DALI 2, Multilumen, Ø90, traffic white (RAL 9016)
Order No.: 51SM13DB11B2C GTIN (EAN): 4069025531247
| Colour temperature | Colour rendering | Beam angle | Luminous flux | Connected load | Luminous efficacy | Control | Dimension (mm) | Colour | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|
| 3000K | CRI > 90 | medium distribution | 4015lm | 31W | 130lm/W | DALI 2, Multilumen | Ø90 | traffic white (RAL 9016) | 1.4 |
Delivery time on request
Spot 21, wide distribution, DALI, Ø90, traffic white (RAL 9016)
Order No.: 51SM14DB11A2C GTIN (EAN): 4069025531391
| Colour temperature | Colour rendering | Beam angle | Luminous flux | Connected load | Luminous efficacy | Control | Dimension (mm) | Colour | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|
| 2700K | CRI > 90 | wide distribution | 3800lm | 31W | 130lm/W | DALI | Ø90 | traffic white (RAL 9016) | 1.4 |
Delivery time on request
Spot 21, wide distribution, DALI, Ø90, traffic white (RAL 9016)
Order No.: 51SM14DB11B2C GTIN (EAN): 4069025531421
| Colour temperature | Colour rendering | Beam angle | Luminous flux | Connected load | Luminous efficacy | Control | Dimension (mm) | Colour | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|
| 3000K | CRI > 90 | wide distribution | 4015lm | 31W | 130lm/W | DALI | Ø90 | traffic white (RAL 9016) | 1.4 |
Delivery time on request
Spot 21, medium distribution, ON/OFF Multilumen, Ø90, traffic white (RAL 9016)
Order No.: 51SM13MB11A2CGTIN (EAN): 4069025531308
| Colour temperature | 2700K |
|---|---|
| Colour rendering | CRI > 90 |
| Beam angle | medium distribution |
| Luminous flux | 3860lm |
| Connected load | 29W |
| Luminous efficacy | 130lm/W |
| Control | ON/OFF Multilumen |
| Dimension (mm) | Ø90 |
| Colour | traffic white (RAL 9016) |
| Wt. (kg) | 1.4 |
Delivery time on request
Spot 21, medium distribution, ON/OFF Multilumen, Ø90, traffic white (RAL 9016)
Order No.: 51SM13MB11B2CGTIN (EAN): 4069025531353
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 90 |
| Beam angle | medium distribution |
| Luminous flux | 3910lm |
| Connected load | 29W |
| Luminous efficacy | 130lm/W |
| Control | ON/OFF Multilumen |
| Dimension (mm) | Ø90 |
| Colour | traffic white (RAL 9016) |
| Wt. (kg) | 1.4 |
Delivery time on request
Spot 21, medium distribution, ON/OFF Multilumen, Ø90, traffic white (RAL 9016)
Order No.: 51SM13MB11D2CGTIN (EAN): 4069025531360
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 90 |
| Beam angle | medium distribution |
| Luminous flux | 4050lm |
| Connected load | 29W |
| Luminous efficacy | 130lm/W |
| Control | ON/OFF Multilumen |
| Dimension (mm) | Ø90 |
| Colour | traffic white (RAL 9016) |
| Wt. (kg) | 1.4 |
Delivery time on request
Spot 21, medium distribution, DALI 2, Multilumen, Ø90, traffic white (RAL 9016)
Order No.: 51SM13DB11D2CGTIN (EAN): 4069025531278
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 90 |
| Beam angle | medium distribution |
| Luminous flux | 4170lm |
| Connected load | 31W |
| Luminous efficacy | 130lm/W |
| Control | DALI 2, Multilumen |
| Dimension (mm) | Ø90 |
| Colour | traffic white (RAL 9016) |
| Wt. (kg) | 1.4 |
Delivery time on request
Spot 21, wide distribution, ON/OFF Multilumen, Ø90, traffic white (RAL 9016)
Order No.: 51SM14MB11A2CGTIN (EAN): 4069025531483
| Colour temperature | 2700K |
|---|---|
| Colour rendering | CRI > 90 |
| Beam angle | wide distribution |
| Luminous flux | 3860lm |
| Connected load | 29W |
| Luminous efficacy | 130lm/W |
| Control | ON/OFF Multilumen |
| Dimension (mm) | Ø90 |
| Colour | traffic white (RAL 9016) |
| Wt. (kg) | 1.4 |
Delivery time on request
Spot 21, wide distribution, ON/OFF Multilumen, Ø90, traffic white (RAL 9016)
Order No.: 51SM14MB11B2CGTIN (EAN): 4069025531537
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 90 |
| Beam angle | wide distribution |
| Luminous flux | 3910lm |
| Connected load | 29W |
| Luminous efficacy | 130lm/W |
| Control | ON/OFF Multilumen |
| Dimension (mm) | Ø90 |
| Colour | traffic white (RAL 9016) |
| Wt. (kg) | 1.4 |
Delivery time on request
Spot 21, wide distribution, ON/OFF Multilumen, Ø90, traffic white (RAL 9016)
Order No.: 51SM14MB11D2CGTIN (EAN): 4069025531544
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 90 |
| Beam angle | wide distribution |
| Luminous flux | 4050lm |
| Connected load | 29W |
| Luminous efficacy | 130lm/W |
| Control | ON/OFF Multilumen |
| Dimension (mm) | Ø90 |
| Colour | traffic white (RAL 9016) |
| Wt. (kg) | 1.4 |
Delivery time on request
Spot 21, wide distribution, DALI, Ø90, traffic white (RAL 9016)
Order No.: 51SM14DB11D2CGTIN (EAN): 4069025531452
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 90 |
| Beam angle | wide distribution |
| Luminous flux | 4170lm |
| Connected load | 31W |
| Luminous efficacy | 130lm/W |
| Control | DALI |
| Dimension (mm) | Ø90 |
| Colour | traffic white (RAL 9016) |
| Wt. (kg) | 1.4 |
Delivery time on request
Spot 21, medium distribution, DALI 2, Multilumen, Ø90, traffic white (RAL 9016)
Order No.: 51SM13DB11A2CGTIN (EAN): 4069025531216
| Colour temperature | 2700K |
|---|---|
| Colour rendering | CRI > 90 |
| Beam angle | medium distribution |
| Luminous flux | 3800lm |
| Connected load | 31W |
| Luminous efficacy | 130lm/W |
| Control | DALI 2, Multilumen |
| Dimension (mm) | Ø90 |
| Colour | traffic white (RAL 9016) |
| Wt. (kg) | 1.4 |
Delivery time on request
Spot 21, medium distribution, DALI 2, Multilumen, Ø90, traffic white (RAL 9016)
Order No.: 51SM13DB11B2CGTIN (EAN): 4069025531247
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 90 |
| Beam angle | medium distribution |
| Luminous flux | 4015lm |
| Connected load | 31W |
| Luminous efficacy | 130lm/W |
| Control | DALI 2, Multilumen |
| Dimension (mm) | Ø90 |
| Colour | traffic white (RAL 9016) |
| Wt. (kg) | 1.4 |
Delivery time on request
Spot 21, wide distribution, DALI, Ø90, traffic white (RAL 9016)
Order No.: 51SM14DB11A2CGTIN (EAN): 4069025531391
| Colour temperature | 2700K |
|---|---|
| Colour rendering | CRI > 90 |
| Beam angle | wide distribution |
| Luminous flux | 3800lm |
| Connected load | 31W |
| Luminous efficacy | 130lm/W |
| Control | DALI |
| Dimension (mm) | Ø90 |
| Colour | traffic white (RAL 9016) |
| Wt. (kg) | 1.4 |
Delivery time on request
Spot 21, wide distribution, DALI, Ø90, traffic white (RAL 9016)
Order No.: 51SM14DB11B2CGTIN (EAN): 4069025531421
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 90 |
| Beam angle | wide distribution |
| Luminous flux | 4015lm |
| Connected load | 31W |
| Luminous efficacy | 130lm/W |
| Control | DALI |
| Dimension (mm) | Ø90 |
| Colour | traffic white (RAL 9016) |
| Wt. (kg) | 1.4 |
