Lantern
Lantern with Module 540 iQ (pre-assembled, incl. connection cable)
Key data
Article mast luminaire
Luminous flux 1510lm to 2970lm
Colour temperature 3000K
Lighting effect direct asymmetric wide distribution; direct asymmetric extremely wide distribution; direct symmetric wide distribution
Light distribution C120006; P100008; S120010
Control iQ Street-Remote; iQ-Street Remote, D4i
Smart Interface above Zhaga
Smart Interface below Zhaga
Protection rating IP65
Insulation class insulation class II (safety insulation)
Special features
Easy installation and low maintenance due to future-oriented modular design for exchangeable LED module and gear tray
Luminous module body as a visual guidance element with decorative day/night time effect
Low energy consumption due to high luminous efficacy and avoidance of overplanning thanks to the patented CLO 2.0 luminous flux tracking
High visual comfort due to uniform illumination and very good glare control – can be further improved with spreader element
Links
Configuration & data sheets
- further light colours and connection cable variants on request
- please order mast reducer separately if required
- luminaire incl. pre-installed connection cable, l = 5.0m
- Setting the luminaire with Street-Remote: with the SITECO iQ app on the SITECO iQ handheld (5EA6HBR02) or your own smart phone
- SITECO offers the SITECO Connect Group Control (230V or 12/24V) product to use the Smart Wire function '10 levels'. A communication module is also available with which remote access is possible and radio clock functionality is provided.
Results
Lantern iQ, direct asymmetric extremely wide distribution, P100008, transparent, standard
Order No.: 5XA5255FF14H000022 GTIN (EAN): 4058352635193
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Smart Interface | Pnom | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|
| 3000K | CRI > 70 | 1510lm | P100008 | iQ Street-Remote | 10.5W | 10.8W | 5.4W | 9.0 |
Lantern iQ, direct asymmetric wide distribution, S120010, transparent, standard
Order No.: 5XA5255EF14H000022 GTIN (EAN): 4058352635179
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Smart Interface | Pnom | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|
| 3000K | CRI > 70 | 1540lm | S120010 | iQ Street-Remote | 10.5W | 10.8W | 5.4W | 9.0 |
Lantern iQ, direct symmetric wide distribution, C120006, transparent, standard
Order No.: 5XA5255JF14H000022 GTIN (EAN): 4058352635995
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Smart Interface | Pnom | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|
| 3000K | CRI > 70 | 2970lm | C120006 | iQ Street-Remote | 19.3W | 20.6W | 9.6W | 9.0 |
Lantern iQ, direct asymmetric wide distribution, S120010, transparent, standard, Z↓
Order No.: 5XA5255EU14H000022 GTIN (EAN): 4058352023945
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Smart Interface | Pnom | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|
| 3000K | CRI > 70 | 1530lm | S120010 | iQ-Street Remote, D4i | Z↓ | 10.7W | 11.1W | 5.6W | 9.0 |
Lantern iQ, direct asymmetric wide distribution, S120010, transparent, standard, Z↑
Order No.: 5XA5255EV14H000022 GTIN (EAN): 4058352023976
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Smart Interface | Pnom | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|
| 3000K | CRI > 70 | 1530lm | S120010 | iQ-Street Remote, D4i | Z↑ | 10.7W | 11.1W | 5.6W | 9.0 |
Lantern iQ, direct asymmetric wide distribution, S120010, transparent, standard, Z↑ Z↓
Order No.: 5XA5255EY14H000022 GTIN (EAN): 4058352023983
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Smart Interface | Pnom | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|
| 3000K | CRI > 70 | 1530lm | S120010 | iQ-Street Remote, D4i | Z↑ Z↓ | 10.7W | 11.1W | 5.6W | 9.0 |
Lantern iQ, direct asymmetric extremely wide distribution, P100008, transparent, standard
Order No.: 5XA5255FF14H000022GTIN (EAN): 4058352635193
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 1510lm |
| Light distribution | P100008 |
| Control | iQ Street-Remote |
| Smart Interface | |
| Pnom | 10.5W |
| Pnom end service life | 10.8W |
| Pred at 50% lumin. flux | 5.4W |
| Wt. (kg) | 9.0 |
Lantern iQ, direct asymmetric wide distribution, S120010, transparent, standard
Order No.: 5XA5255EF14H000022GTIN (EAN): 4058352635179
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 1540lm |
| Light distribution | S120010 |
| Control | iQ Street-Remote |
| Smart Interface | |
| Pnom | 10.5W |
| Pnom end service life | 10.8W |
| Pred at 50% lumin. flux | 5.4W |
| Wt. (kg) | 9.0 |
Lantern iQ, direct symmetric wide distribution, C120006, transparent, standard
Order No.: 5XA5255JF14H000022GTIN (EAN): 4058352635995
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 2970lm |
| Light distribution | C120006 |
| Control | iQ Street-Remote |
| Smart Interface | |
| Pnom | 19.3W |
| Pnom end service life | 20.6W |
| Pred at 50% lumin. flux | 9.6W |
| Wt. (kg) | 9.0 |
Lantern iQ, direct asymmetric wide distribution, S120010, transparent, standard, Z↓
Order No.: 5XA5255EU14H000022GTIN (EAN): 4058352023945
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 1530lm |
| Light distribution | S120010 |
| Control | iQ-Street Remote, D4i |
| Smart Interface | Z↓ |
| Pnom | 10.7W |
| Pnom end service life | 11.1W |
| Pred at 50% lumin. flux | 5.6W |
| Wt. (kg) | 9.0 |
Lantern iQ, direct asymmetric wide distribution, S120010, transparent, standard, Z↑
Order No.: 5XA5255EV14H000022GTIN (EAN): 4058352023976
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 1530lm |
| Light distribution | S120010 |
| Control | iQ-Street Remote, D4i |
| Smart Interface | Z↑ |
| Pnom | 10.7W |
| Pnom end service life | 11.1W |
| Pred at 50% lumin. flux | 5.6W |
| Wt. (kg) | 9.0 |
Lantern iQ, direct asymmetric wide distribution, S120010, transparent, standard, Z↑ Z↓
Order No.: 5XA5255EY14H000022GTIN (EAN): 4058352023983
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 1530lm |
| Light distribution | S120010 |
| Control | iQ-Street Remote, D4i |
| Smart Interface | Z↑ Z↓ |
| Pnom | 10.7W |
| Pnom end service life | 11.1W |
| Pred at 50% lumin. flux | 5.6W |
| Wt. (kg) | 9.0 |
