SITECO

Lantern

Application Configuration & data sheets

Lantern with Module 540 iQ (as single components)

Key data

Article mast luminaire
Luminous flux 1510lm to 4940lm
Colour temperature 2200K; 2700K; 3000K; 4000K
Lighting effect direct asymmetric wide distribution; direct asymmetric extremely wide distribution; direct symmetric wide distribution
Light distribution C120006; P100008; S120010
Control iQ Street-Remote
Protection rating IP65
Insulation class insulation class II (safety insulation)

Special features

Easy installation and low maintenance due to future-oriented modular design for exchangeable LED module and gear tray
Luminous module body as a visual guidance element with decorative day/night time effect
Low energy consumption due to high luminous efficacy and avoidance of overplanning thanks to the patented CLO 2.0 luminous flux tracking
High visual comfort due to uniform illumination and very good glare control – can be further improved with spreader element

Links

To the product page

Configuration & data sheets

Lighting effect

Light distribution

Light distribution

Colour temperature

Equipment

  • please order mast reducer separately if required
  • Setting the luminaire with Street-Remote: with the SITECO iQ app on the SITECO iQ handheld (5EA6HBR02) or your own smart phone
  • SITECO offers the product SITECO Connect Group Control (230V or 12/24V) for using the SmartWire function '10 levels'. Also available is a communication module that allows remote access and radio clock functionality
  • We offer luminaires with a Smart Interface (Zhaga) in our pre-assembled versions

Results

Lantern iQ, direct asymmetric extremely wide distribution, P100008, transparent, standard

Order No.: 5XA5255BF14H GTIN (EAN): 4058352833421
Colour temperatureColour renderingLuminous fluxLight distributionControlPnomPnom end service lifePred at 50% lumin. fluxWt. (kg)
2200KCRI > 701510lmP100008iQ Street-Remote12.9W13.3W6.4W9.9
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Lantern iQ, direct asymmetric extremely wide distribution, P100008, transparent, Power

Order No.: 5XA5255BF14HP GTIN (EAN): 4058352833445
Colour temperatureColour renderingLuminous fluxLight distributionControlPnomPnom end service lifePred at 50% lumin. fluxWt. (kg)
2200KCRI > 703890lmP100008iQ Street-Remote33.6W35.9W15.2W9.9
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Lantern iQ, direct asymmetric wide distribution, S120010, transparent, standard

Order No.: 5XA5255AF14H GTIN (EAN): 4058352833384
Colour temperatureColour renderingLuminous fluxLight distributionControlPnomPnom end service lifePred at 50% lumin. fluxWt. (kg)
2200KCRI > 701540lmS120010iQ Street-Remote12.9W13.3W6.4W9.9
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Lantern iQ, direct asymmetric wide distribution, S120010, transparent, Power

Order No.: 5XA5255AF14HP GTIN (EAN): 4058352833407
Colour temperatureColour renderingLuminous fluxLight distributionControlPnomPnom end service lifePred at 50% lumin. fluxWt. (kg)
2200KCRI > 703910lmS120010iQ Street-Remote33.6W35.9W15.2W9.9
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Lantern iQ, direct symmetric wide distribution, C120006, transparent, standard

Order No.: 5XA5255CF14H GTIN (EAN): 4058352833476
Colour temperatureColour renderingLuminous fluxLight distributionControlPnomPnom end service lifePred at 50% lumin. fluxWt. (kg)
2200KCRI > 702970lmC120006iQ Street-Remote23.9W25.5W11.5W9.9
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Lantern iQ, direct asymmetric extremely wide distribution, P100008, transparent, standard

Order No.: 5XA5255NF14H GTIN (EAN): 4058352833612
Colour temperatureColour renderingLuminous fluxLight distributionControlPnomPnom end service lifePred at 50% lumin. fluxWt. (kg)
2700KCRI > 701510lmP100008iQ Street-Remote11.8W12.1W6W9.9
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Lantern iQ, direct asymmetric extremely wide distribution, P100008, transparent, Power

Order No.: 5XA5255NF14HP GTIN (EAN): 4058352833629
Colour temperatureColour renderingLuminous fluxLight distributionControlPnomPnom end service lifePred at 50% lumin. fluxWt. (kg)
2700KCRI > 704210lmP100008iQ Street-Remote33.6W35.9W15.2W9.9
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Lantern iQ, direct asymmetric wide distribution, S120010, transparent, standard

Order No.: 5XA5255MF14H GTIN (EAN): 4058352833568
Colour temperatureColour renderingLuminous fluxLight distributionControlPnomPnom end service lifePred at 50% lumin. fluxWt. (kg)
2700KCRI > 701540lmS120010iQ Street-Remote11.8W12.1W6W9.9
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Lantern iQ, direct asymmetric wide distribution, S120010, transparent, Power

Order No.: 5XA5255MF14HP GTIN (EAN): 4058352833582
Colour temperatureColour renderingLuminous fluxLight distributionControlPnomPnom end service lifePred at 50% lumin. fluxWt. (kg)
2700KCRI > 704240lmS120010iQ Street-Remote33.6W35.9W15.2W9.9
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Lantern iQ, direct symmetric wide distribution, C120006, transparent, standard

Order No.: 5XA5255OF14H GTIN (EAN): 4058352833643
Colour temperatureColour renderingLuminous fluxLight distributionControlPnomPnom end service lifePred at 50% lumin. fluxWt. (kg)
2700KCRI > 702970lmC120006iQ Street-Remote21.8W23.2W10.7W9.9
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Lantern iQ, direct asymmetric extremely wide distribution, P100008, transparent, standard

Order No.: 5XA5255FF14H GTIN (EAN): 4058352635964
Colour temperatureColour renderingLuminous fluxLight distributionControlPnomPnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 701510lmP100008iQ Street-Remote10.5W10.8W5.4W9.9
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Lantern iQ, direct asymmetric extremely wide distribution, P100008, transparent, Power

Order No.: 5XA5255FF14HP GTIN (EAN): 4058352834756
Colour temperatureColour renderingLuminous fluxLight distributionControlPnomPnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 704700lmP100008iQ Street-Remote33.6W35.9W15.2W9.9
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Lantern iQ, direct asymmetric wide distribution, S120010, transparent, standard

Order No.: 5XA5255EF14H GTIN (EAN): 4058352635933
Colour temperatureColour renderingLuminous fluxLight distributionControlPnomPnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 701540lmS120010iQ Street-Remote10.5W10.8W5.4W9.9
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Lantern iQ, direct asymmetric wide distribution, S120010, transparent, Power

Order No.: 5XA5255EF14HP GTIN (EAN): 4058352834060
Colour temperatureColour renderingLuminous fluxLight distributionControlPnomPnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 704730lmS120010iQ Street-Remote33.6W35.9W15.2W9.9
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Lantern iQ, direct symmetric wide distribution, C120006, transparent, standard

Order No.: 5XA5255JF14H GTIN (EAN): 4058352635971
Colour temperatureColour renderingLuminous fluxLight distributionControlPnomPnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 702970lmC120006iQ Street-Remote19.3W20.6W9.6W9.9
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Lantern iQ, direct asymmetric extremely wide distribution, P100008, transparent, standard

Order No.: 5XA5255LF14H GTIN (EAN): 4058352833520
Colour temperatureColour renderingLuminous fluxLight distributionControlPnomPnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 701510lmP100008iQ Street-Remote10W10.4W5.3W9.9
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Lantern iQ, direct asymmetric extremely wide distribution, P100008, transparent, Power

Order No.: 5XA5255LF14HP GTIN (EAN): 4058352833544
Colour temperatureColour renderingLuminous fluxLight distributionControlPnomPnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 704910lmP100008iQ Street-Remote33.6W35.9W15.3W9.9
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Lantern iQ, direct asymmetric wide distribution, S120010, transparent, standard

Order No.: 5XA5255KF14H GTIN (EAN): 4058352833483
Colour temperatureColour renderingLuminous fluxLight distributionControlPnomPnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 701540lmS120010iQ Street-Remote10W10.4W5.3W9.9
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Lantern iQ, direct asymmetric wide distribution, S120010, transparent, Power

Order No.: 5XA5255KF14HP GTIN (EAN): 4058352833506
Colour temperatureColour renderingLuminous fluxLight distributionControlPnomPnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 704940lmS120010iQ Street-Remote33.6W35.9W15.3W9.9
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Lantern iQ, direct symmetric wide distribution, C120006, transparent, standard

Order No.: 5XA5255RF14H GTIN (EAN): 4058352833667
Colour temperatureColour renderingLuminous fluxLight distributionControlPnomPnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 702970lmC120006iQ Street-Remote18.5W19.7W9.3W9.9
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Lantern iQ, direct asymmetric extremely wide distribution, P100008, transparent, standard

Order No.: 5XA5255BF14HGTIN (EAN): 4058352833421

Colour temperature2200K
Colour renderingCRI > 70
Luminous flux1510lm
Light distributionP100008
ControliQ Street-Remote
Pnom12.9W
Pnom end service life13.3W
Pred at 50% lumin. flux6.4W
Wt. (kg)9.9
Show all details

Lantern iQ, direct asymmetric extremely wide distribution, P100008, transparent, Power

Order No.: 5XA5255BF14HPGTIN (EAN): 4058352833445

Colour temperature2200K
Colour renderingCRI > 70
Luminous flux3890lm
Light distributionP100008
ControliQ Street-Remote
Pnom33.6W
Pnom end service life35.9W
Pred at 50% lumin. flux15.2W
Wt. (kg)9.9
Show all details

Lantern iQ, direct asymmetric wide distribution, S120010, transparent, standard

Order No.: 5XA5255AF14HGTIN (EAN): 4058352833384

Colour temperature2200K
Colour renderingCRI > 70
Luminous flux1540lm
Light distributionS120010
ControliQ Street-Remote
Pnom12.9W
Pnom end service life13.3W
Pred at 50% lumin. flux6.4W
Wt. (kg)9.9
Show all details

Lantern iQ, direct asymmetric wide distribution, S120010, transparent, Power

Order No.: 5XA5255AF14HPGTIN (EAN): 4058352833407

Colour temperature2200K
Colour renderingCRI > 70
Luminous flux3910lm
Light distributionS120010
ControliQ Street-Remote
Pnom33.6W
Pnom end service life35.9W
Pred at 50% lumin. flux15.2W
Wt. (kg)9.9
Show all details

Lantern iQ, direct symmetric wide distribution, C120006, transparent, standard

Order No.: 5XA5255CF14HGTIN (EAN): 4058352833476

Colour temperature2200K
Colour renderingCRI > 70
Luminous flux2970lm
Light distributionC120006
ControliQ Street-Remote
Pnom23.9W
Pnom end service life25.5W
Pred at 50% lumin. flux11.5W
Wt. (kg)9.9
Show all details

Lantern iQ, direct asymmetric extremely wide distribution, P100008, transparent, standard

Order No.: 5XA5255NF14HGTIN (EAN): 4058352833612

Colour temperature2700K
Colour renderingCRI > 70
Luminous flux1510lm
Light distributionP100008
ControliQ Street-Remote
Pnom11.8W
Pnom end service life12.1W
Pred at 50% lumin. flux6W
Wt. (kg)9.9
Show all details

Lantern iQ, direct asymmetric extremely wide distribution, P100008, transparent, Power

Order No.: 5XA5255NF14HPGTIN (EAN): 4058352833629

Colour temperature2700K
Colour renderingCRI > 70
Luminous flux4210lm
Light distributionP100008
ControliQ Street-Remote
Pnom33.6W
Pnom end service life35.9W
Pred at 50% lumin. flux15.2W
Wt. (kg)9.9
Show all details

Lantern iQ, direct asymmetric wide distribution, S120010, transparent, standard

Order No.: 5XA5255MF14HGTIN (EAN): 4058352833568

Colour temperature2700K
Colour renderingCRI > 70
Luminous flux1540lm
Light distributionS120010
ControliQ Street-Remote
Pnom11.8W
Pnom end service life12.1W
Pred at 50% lumin. flux6W
Wt. (kg)9.9
Show all details

Lantern iQ, direct asymmetric wide distribution, S120010, transparent, Power

Order No.: 5XA5255MF14HPGTIN (EAN): 4058352833582

Colour temperature2700K
Colour renderingCRI > 70
Luminous flux4240lm
Light distributionS120010
ControliQ Street-Remote
Pnom33.6W
Pnom end service life35.9W
Pred at 50% lumin. flux15.2W
Wt. (kg)9.9
Show all details

Lantern iQ, direct symmetric wide distribution, C120006, transparent, standard

Order No.: 5XA5255OF14HGTIN (EAN): 4058352833643

Colour temperature2700K
Colour renderingCRI > 70
Luminous flux2970lm
Light distributionC120006
ControliQ Street-Remote
Pnom21.8W
Pnom end service life23.2W
Pred at 50% lumin. flux10.7W
Wt. (kg)9.9
Show all details

Lantern iQ, direct asymmetric extremely wide distribution, P100008, transparent, standard

Order No.: 5XA5255FF14HGTIN (EAN): 4058352635964

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux1510lm
Light distributionP100008
ControliQ Street-Remote
Pnom10.5W
Pnom end service life10.8W
Pred at 50% lumin. flux5.4W
Wt. (kg)9.9
Show all details

Lantern iQ, direct asymmetric extremely wide distribution, P100008, transparent, Power

Order No.: 5XA5255FF14HPGTIN (EAN): 4058352834756

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux4700lm
Light distributionP100008
ControliQ Street-Remote
Pnom33.6W
Pnom end service life35.9W
Pred at 50% lumin. flux15.2W
Wt. (kg)9.9
Show all details

Lantern iQ, direct asymmetric wide distribution, S120010, transparent, standard

Order No.: 5XA5255EF14HGTIN (EAN): 4058352635933

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux1540lm
Light distributionS120010
ControliQ Street-Remote
Pnom10.5W
Pnom end service life10.8W
Pred at 50% lumin. flux5.4W
Wt. (kg)9.9
Show all details

Lantern iQ, direct asymmetric wide distribution, S120010, transparent, Power

Order No.: 5XA5255EF14HPGTIN (EAN): 4058352834060

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux4730lm
Light distributionS120010
ControliQ Street-Remote
Pnom33.6W
Pnom end service life35.9W
Pred at 50% lumin. flux15.2W
Wt. (kg)9.9
Show all details

Lantern iQ, direct symmetric wide distribution, C120006, transparent, standard

Order No.: 5XA5255JF14HGTIN (EAN): 4058352635971

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux2970lm
Light distributionC120006
ControliQ Street-Remote
Pnom19.3W
Pnom end service life20.6W
Pred at 50% lumin. flux9.6W
Wt. (kg)9.9
Show all details

Lantern iQ, direct asymmetric extremely wide distribution, P100008, transparent, standard

Order No.: 5XA5255LF14HGTIN (EAN): 4058352833520

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux1510lm
Light distributionP100008
ControliQ Street-Remote
Pnom10W
Pnom end service life10.4W
Pred at 50% lumin. flux5.3W
Wt. (kg)9.9
Show all details

Lantern iQ, direct asymmetric extremely wide distribution, P100008, transparent, Power

Order No.: 5XA5255LF14HPGTIN (EAN): 4058352833544

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux4910lm
Light distributionP100008
ControliQ Street-Remote
Pnom33.6W
Pnom end service life35.9W
Pred at 50% lumin. flux15.3W
Wt. (kg)9.9
Show all details

Lantern iQ, direct asymmetric wide distribution, S120010, transparent, standard

Order No.: 5XA5255KF14HGTIN (EAN): 4058352833483

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux1540lm
Light distributionS120010
ControliQ Street-Remote
Pnom10W
Pnom end service life10.4W
Pred at 50% lumin. flux5.3W
Wt. (kg)9.9
Show all details

Lantern iQ, direct asymmetric wide distribution, S120010, transparent, Power

Order No.: 5XA5255KF14HPGTIN (EAN): 4058352833506

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux4940lm
Light distributionS120010
ControliQ Street-Remote
Pnom33.6W
Pnom end service life35.9W
Pred at 50% lumin. flux15.3W
Wt. (kg)9.9
Show all details

Lantern iQ, direct symmetric wide distribution, C120006, transparent, standard

Order No.: 5XA5255RF14HGTIN (EAN): 4058352833667

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux2970lm
Light distributionC120006
ControliQ Street-Remote
Pnom18.5W
Pnom end service life19.7W
Pred at 50% lumin. flux9.3W
Wt. (kg)9.9
Show all details

Optional accessories

Articlespreader elementPU1 pc.Wt. (kg)0.2Order No.: 5XA54000XSGTIN (EAN): 4050737730073Show all details
Articlespreader elementPU1 pc.Wt. (kg)0.2Order No.: 5XA54000XSAGTIN (EAN): 4058352161326Show all details
Articleshield, rear shieldingPU1 pc.Wt. (kg)0.1Order No.: 5XA54000XBSGTIN (EAN): 4050737971445Show all details
Articleshield, rear shieldingPU1 pc.Wt. (kg)0.1Order No.: 5XA54000XBLGTIN (EAN): 4050737971421Show all details
Articleshield, rear shieldingPU1 pc.Wt. (kg)0.5Order No.: 5XA54000XBXLGTIN (EAN): 4058352415573Show all details
Articledecorative ring, silverPU1 pc.Wt. (kg)0.2Order No.: 5XA54001XSGTIN (EAN): 4050737754895Show all details
Articlecable junction box, 2x E14, for 3 cables to 5x 16mm²PU1 pc.Wt. (kg)0.8Order No.: 5NY70062DKGTIN (EAN): 4058352552247Show all details
Articlecover, PMMA, transparent, ø= 185mmPU1 pc.Wt. (kg)2.0Order No.: 5NC54700XGGTIN (EAN): 4039806180513Show all details
