SITECO
Licross
Product selection
Licross Wallwasher/Shelfwasher IP40
Key data
Article luminaire insert
Protection rating IP20
Net luminous flux 5030lm to 5360lm
Colour temperature 3000K; 4000K
Lighting effect asymmetric distribution, wallwasher; asymmetric distribution, shelfwasher; asymmetric right distribution, shelfwasher
Special features
Accentuated lighting and outstanding colour rendering for attractive displays of merchandise
With four asymmetric wide distribution single reflectors for uniform light distribution over the entire shelf height with reduced luminance in the upper area
Harmonious housing design with a slender shape and simultaneously high flexibility due to numerous configuration options
Supplementary reflector for aisle illumination as optional accessory
Configuration & data sheets
- please order Licross trunking rails and trunking rail accessories separately
Results
Licross Wallwasher, traffic white (RAL 9016)
Order No.: 51TH1W7D36XA GTIN (EAN): 4058352329559
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Luminous efficacy | Control | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|
| 3000K | CRI > 80 | 5030 | 45W | 112lm/W | ON/OFF | IP20 | 600 | 1.5 |
Licross Wallwasher, traffic white (RAL 9016)
Order No.: 51TH1WDD36XA GTIN (EAN): 4058352329580
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Luminous efficacy | Control | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|
| 3000K | CRI > 80 | 5030 | 45W | 112lm/W | DALI | IP20 | 600 | 1.5 |
Licross Wallwasher, jet black (RAL 9005)
Order No.: 51TH3WDD36XA GTIN (EAN): 4058352329740
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Luminous efficacy | Control | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|
| 3000K | CRI > 80 | 5030 | 45W | 112lm/W | DALI | IP20 | 600 | 1.5 |
Licross Wallwasher, jet black (RAL 9005)
Order No.: 51TH3WDD46XA GTIN (EAN): 4058352329764
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Luminous efficacy | Control | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 5270 | 45W | 117lm/W | DALI | IP20 | 600 | 1.5 |
Licross Shelfwasher, jet black (RAL 9005)
Order No.: 51TH3SDD36XA GTIN (EAN): 4058352329641
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Luminous efficacy | Control | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|
| 3000K | CRI > 80 | 5120 | 45W | 114lm/W | DALI | IP20 | 600 | 1.5 |
Licross Shelfwasher, jet black (RAL 9005)
Order No.: 51TH3SDD46XA GTIN (EAN): 4058352329665
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Luminous efficacy | Control | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 5360 | 45W | 119lm/W | DALI | IP20 | 600 | 1.5 |
Licross Shelfwasher, traffic white (RAL 9016)
Order No.: 51TH1SDD36XA GTIN (EAN): 4058352329481
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Luminous efficacy | Control | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|
| 3000K | CRI > 80 | 5120 | 45W | 114lm/W | DALI | IP20 | 600 | 1.5 |
Licross Wallwasher, traffic white (RAL 9016)
Order No.: 51TH1W7D36XAGTIN (EAN): 4058352329559
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 5030 |
| Connected load | 45W |
| Luminous efficacy | 112lm/W |
| Control | ON/OFF |
| Protection rating | IP20 |
| L (mm) | 600 |
| Wt. (kg) | 1.5 |
Licross Wallwasher, traffic white (RAL 9016)
Order No.: 51TH1WDD36XAGTIN (EAN): 4058352329580
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 5030 |
| Connected load | 45W |
| Luminous efficacy | 112lm/W |
| Control | DALI |
| Protection rating | IP20 |
| L (mm) | 600 |
| Wt. (kg) | 1.5 |
Licross Wallwasher, jet black (RAL 9005)
Order No.: 51TH3WDD36XAGTIN (EAN): 4058352329740
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 5030 |
| Connected load | 45W |
| Luminous efficacy | 112lm/W |
| Control | DALI |
| Protection rating | IP20 |
| L (mm) | 600 |
| Wt. (kg) | 1.5 |
Licross Wallwasher, jet black (RAL 9005)
Order No.: 51TH3WDD46XAGTIN (EAN): 4058352329764
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 5270 |
| Connected load | 45W |
| Luminous efficacy | 117lm/W |
| Control | DALI |
| Protection rating | IP20 |
| L (mm) | 600 |
| Wt. (kg) | 1.5 |
Licross Shelfwasher, jet black (RAL 9005)
Order No.: 51TH3SDD36XAGTIN (EAN): 4058352329641
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 5120 |
| Connected load | 45W |
| Luminous efficacy | 114lm/W |
| Control | DALI |
| Protection rating | IP20 |
| L (mm) | 600 |
| Wt. (kg) | 1.5 |
Licross Shelfwasher, jet black (RAL 9005)
Order No.: 51TH3SDD46XAGTIN (EAN): 4058352329665
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 5360 |
| Connected load | 45W |
| Luminous efficacy | 119lm/W |
| Control | DALI |
| Protection rating | IP20 |
| L (mm) | 600 |
| Wt. (kg) | 1.5 |
Licross Shelfwasher, traffic white (RAL 9016)
Order No.: 51TH1SDD36XAGTIN (EAN): 4058352329481
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 5120 |
| Connected load | 45W |
| Luminous efficacy | 114lm/W |
| Control | DALI |
| Protection rating | IP20 |
| L (mm) | 600 |
| Wt. (kg) | 1.5 |
