Lantern
Lantern with Module 540 iQ (as single components)

Key data
Article mast luminaire
Luminous flux 1510lm to 4940lm
Colour temperature 2200K; 2700K; 3000K; 4000K
Lighting effect direct asymmetric wide distribution; direct asymmetric extremely wide distribution; direct symmetric wide distribution
Light distribution C120006; P100008; S120010
Control iQ Street-Remote
Protection rating IP65
Insulation class insulation class II (safety insulation)
Special features
Links
Configuration & data sheets
- please order mast reducer separately if required
- Setting the luminaire with Street-Remote: with the SITECO iQ app on the SITECO iQ handheld (5EA6HBR02) or your own smart phone
- SITECO offers the product SITECO Connect Group Control (230V or 12/24V) for using the SmartWire function '10 levels'. Also available is a communication module that allows remote access and radio clock functionality
- We offer luminaires with a Smart Interface (Zhaga) in our pre-assembled versions
Results
Lantern iQ, direct asymmetric extremely wide distribution, P100008, transparent, standard
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 2200K | CRI > 70 | 1510lm | P100008 | iQ Street-Remote | 12.9W | 13.3W | 6.4W | 9.9 | 1468.00 |
Lantern iQ, direct asymmetric extremely wide distribution, P100008, transparent, Power
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 2200K | CRI > 70 | 3890lm | P100008 | iQ Street-Remote | 33.6W | 35.9W | 15.2W | 9.9 | 1540.00 |
Lantern iQ, direct asymmetric wide distribution, S120010, transparent, standard
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 2200K | CRI > 70 | 1540lm | S120010 | iQ Street-Remote | 12.9W | 13.3W | 6.4W | 9.9 | 1468.00 |
Lantern iQ, direct asymmetric wide distribution, S120010, transparent, Power
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 2200K | CRI > 70 | 3910lm | S120010 | iQ Street-Remote | 33.6W | 35.9W | 15.2W | 9.9 | 1540.00 |
Lantern iQ, direct symmetric wide distribution, C120006, transparent, standard
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 2200K | CRI > 70 | 2970lm | C120006 | iQ Street-Remote | 23.9W | 25.5W | 11.5W | 9.9 | 1611.00 |
Lantern iQ, direct asymmetric extremely wide distribution, P100008, transparent, standard
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 2700K | CRI > 70 | 1510lm | P100008 | iQ Street-Remote | 11.8W | 12.1W | 6W | 9.9 | 1468.00 |
Lantern iQ, direct asymmetric extremely wide distribution, P100008, transparent, Power
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 2700K | CRI > 70 | 4210lm | P100008 | iQ Street-Remote | 33.6W | 35.9W | 15.2W | 9.9 | 1540.00 |
Lantern iQ, direct asymmetric wide distribution, S120010, transparent, standard
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 2700K | CRI > 70 | 1540lm | S120010 | iQ Street-Remote | 11.8W | 12.1W | 6W | 9.9 | 1468.00 |
Lantern iQ, direct asymmetric wide distribution, S120010, transparent, Power
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 2700K | CRI > 70 | 4240lm | S120010 | iQ Street-Remote | 33.6W | 35.9W | 15.2W | 9.9 | 1540.00 |
Lantern iQ, direct symmetric wide distribution, C120006, transparent, standard
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 2700K | CRI > 70 | 2970lm | C120006 | iQ Street-Remote | 21.8W | 23.2W | 10.7W | 9.9 | 1611.00 |
Lantern iQ, direct asymmetric extremely wide distribution, P100008, transparent, standard
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 3000K | CRI > 70 | 1510lm | P100008 | iQ Street-Remote | 10.5W | 10.8W | 5.4W | 9.9 | 1459.20 |
Lantern iQ, direct asymmetric extremely wide distribution, P100008, transparent, Power
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 3000K | CRI > 70 | 4700lm | P100008 | iQ Street-Remote | 33.6W | 35.9W | 15.2W | 9.9 | 1537.30 |
Lantern iQ, direct asymmetric wide distribution, S120010, transparent, standard
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 3000K | CRI > 70 | 1540lm | S120010 | iQ Street-Remote | 10.5W | 10.8W | 5.4W | 9.9 | 1459.20 |
Lantern iQ, direct asymmetric wide distribution, S120010, transparent, Power
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 3000K | CRI > 70 | 4730lm | S120010 | iQ Street-Remote | 33.6W | 35.9W | 15.2W | 9.9 | 1537.30 |
Lantern iQ, direct symmetric wide distribution, C120006, transparent, standard
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 3000K | CRI > 70 | 2970lm | C120006 | iQ Street-Remote | 19.3W | 20.6W | 9.6W | 9.9 | 1537.30 |
Lantern iQ, direct asymmetric extremely wide distribution, P100008, transparent, standard
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 70 | 1510lm | P100008 | iQ Street-Remote | 10W | 10.4W | 5.3W | 9.9 | 1432.00 |
Lantern iQ, direct asymmetric extremely wide distribution, P100008, transparent, Power
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 70 | 4910lm | P100008 | iQ Street-Remote | 33.6W | 35.9W | 15.3W | 9.9 | 1504.00 |
Lantern iQ, direct asymmetric wide distribution, S120010, transparent, standard
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 70 | 1540lm | S120010 | iQ Street-Remote | 10W | 10.4W | 5.3W | 9.9 | 1566.30 |
Lantern iQ, direct asymmetric wide distribution, S120010, transparent, Power
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 70 | 4940lm | S120010 | iQ Street-Remote | 33.6W | 35.9W | 15.3W | 9.9 | 1504.00 |
Lantern iQ, direct symmetric wide distribution, C120006, transparent, standard
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 70 | 2970lm | C120006 | iQ Street-Remote | 18.5W | 19.7W | 9.3W | 9.9 | 1723.80 |
Lantern iQ, direct asymmetric extremely wide distribution, P100008, transparent, standard
Order No.: 5XA5255BF14HGTIN (EAN): 4058352833421
| Colour temperature | 2200K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 1510lm |
| Light distribution | P100008 |
| Control | iQ Street-Remote |
| Pnom | 12.9W |
| Pnom end service life | 13.3W |
| Pred at 50% lumin. flux | 6.4W |
| Wt. (kg) | 9.9 |
| Price (EUR) | 1468.00 |
Lantern iQ, direct asymmetric extremely wide distribution, P100008, transparent, Power
Order No.: 5XA5255BF14HPGTIN (EAN): 4058352833445
| Colour temperature | 2200K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 3890lm |
| Light distribution | P100008 |
| Control | iQ Street-Remote |
| Pnom | 33.6W |
| Pnom end service life | 35.9W |
| Pred at 50% lumin. flux | 15.2W |
| Wt. (kg) | 9.9 |
| Price (EUR) | 1540.00 |
Lantern iQ, direct asymmetric wide distribution, S120010, transparent, standard
Order No.: 5XA5255AF14HGTIN (EAN): 4058352833384
| Colour temperature | 2200K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 1540lm |
| Light distribution | S120010 |
| Control | iQ Street-Remote |
| Pnom | 12.9W |
| Pnom end service life | 13.3W |
| Pred at 50% lumin. flux | 6.4W |
| Wt. (kg) | 9.9 |
| Price (EUR) | 1468.00 |
Lantern iQ, direct asymmetric wide distribution, S120010, transparent, Power
Order No.: 5XA5255AF14HPGTIN (EAN): 4058352833407
| Colour temperature | 2200K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 3910lm |
| Light distribution | S120010 |
| Control | iQ Street-Remote |
| Pnom | 33.6W |
| Pnom end service life | 35.9W |
| Pred at 50% lumin. flux | 15.2W |
| Wt. (kg) | 9.9 |
| Price (EUR) | 1540.00 |
Lantern iQ, direct symmetric wide distribution, C120006, transparent, standard
Order No.: 5XA5255CF14HGTIN (EAN): 4058352833476
| Colour temperature | 2200K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 2970lm |
| Light distribution | C120006 |
| Control | iQ Street-Remote |
| Pnom | 23.9W |
| Pnom end service life | 25.5W |
| Pred at 50% lumin. flux | 11.5W |
| Wt. (kg) | 9.9 |
| Price (EUR) | 1611.00 |
Lantern iQ, direct asymmetric extremely wide distribution, P100008, transparent, standard
Order No.: 5XA5255NF14HGTIN (EAN): 4058352833612
| Colour temperature | 2700K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 1510lm |
| Light distribution | P100008 |
| Control | iQ Street-Remote |
| Pnom | 11.8W |
| Pnom end service life | 12.1W |
| Pred at 50% lumin. flux | 6W |
| Wt. (kg) | 9.9 |
| Price (EUR) | 1468.00 |
Lantern iQ, direct asymmetric extremely wide distribution, P100008, transparent, Power
Order No.: 5XA5255NF14HPGTIN (EAN): 4058352833629
| Colour temperature | 2700K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 4210lm |
| Light distribution | P100008 |
| Control | iQ Street-Remote |
| Pnom | 33.6W |
| Pnom end service life | 35.9W |
| Pred at 50% lumin. flux | 15.2W |
| Wt. (kg) | 9.9 |
| Price (EUR) | 1540.00 |
Lantern iQ, direct asymmetric wide distribution, S120010, transparent, standard
Order No.: 5XA5255MF14HGTIN (EAN): 4058352833568
| Colour temperature | 2700K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 1540lm |
| Light distribution | S120010 |
| Control | iQ Street-Remote |
| Pnom | 11.8W |
| Pnom end service life | 12.1W |
| Pred at 50% lumin. flux | 6W |
| Wt. (kg) | 9.9 |
| Price (EUR) | 1468.00 |
Lantern iQ, direct asymmetric wide distribution, S120010, transparent, Power
Order No.: 5XA5255MF14HPGTIN (EAN): 4058352833582
| Colour temperature | 2700K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 4240lm |
| Light distribution | S120010 |
| Control | iQ Street-Remote |
| Pnom | 33.6W |
| Pnom end service life | 35.9W |
| Pred at 50% lumin. flux | 15.2W |
| Wt. (kg) | 9.9 |
| Price (EUR) | 1540.00 |
Lantern iQ, direct symmetric wide distribution, C120006, transparent, standard
Order No.: 5XA5255OF14HGTIN (EAN): 4058352833643
| Colour temperature | 2700K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 2970lm |
| Light distribution | C120006 |
| Control | iQ Street-Remote |
| Pnom | 21.8W |
| Pnom end service life | 23.2W |
| Pred at 50% lumin. flux | 10.7W |
| Wt. (kg) | 9.9 |
| Price (EUR) | 1611.00 |
Lantern iQ, direct asymmetric extremely wide distribution, P100008, transparent, standard
Order No.: 5XA5255FF14HGTIN (EAN): 4058352635964
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 1510lm |
| Light distribution | P100008 |
| Control | iQ Street-Remote |
| Pnom | 10.5W |
| Pnom end service life | 10.8W |
| Pred at 50% lumin. flux | 5.4W |
| Wt. (kg) | 9.9 |
| Price (EUR) | 1459.20 |
Lantern iQ, direct asymmetric extremely wide distribution, P100008, transparent, Power
Order No.: 5XA5255FF14HPGTIN (EAN): 4058352834756
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 4700lm |
| Light distribution | P100008 |
| Control | iQ Street-Remote |
| Pnom | 33.6W |
| Pnom end service life | 35.9W |
| Pred at 50% lumin. flux | 15.2W |
| Wt. (kg) | 9.9 |
| Price (EUR) | 1537.30 |
Lantern iQ, direct asymmetric wide distribution, S120010, transparent, standard
Order No.: 5XA5255EF14HGTIN (EAN): 4058352635933
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 1540lm |
| Light distribution | S120010 |
| Control | iQ Street-Remote |
| Pnom | 10.5W |
| Pnom end service life | 10.8W |
| Pred at 50% lumin. flux | 5.4W |
| Wt. (kg) | 9.9 |
| Price (EUR) | 1459.20 |
Lantern iQ, direct asymmetric wide distribution, S120010, transparent, Power
Order No.: 5XA5255EF14HPGTIN (EAN): 4058352834060
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 4730lm |
| Light distribution | S120010 |
| Control | iQ Street-Remote |
| Pnom | 33.6W |
| Pnom end service life | 35.9W |
| Pred at 50% lumin. flux | 15.2W |
| Wt. (kg) | 9.9 |
| Price (EUR) | 1537.30 |
Lantern iQ, direct symmetric wide distribution, C120006, transparent, standard
Order No.: 5XA5255JF14HGTIN (EAN): 4058352635971
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 2970lm |
| Light distribution | C120006 |
| Control | iQ Street-Remote |
| Pnom | 19.3W |
| Pnom end service life | 20.6W |
| Pred at 50% lumin. flux | 9.6W |
| Wt. (kg) | 9.9 |
| Price (EUR) | 1537.30 |
Lantern iQ, direct asymmetric extremely wide distribution, P100008, transparent, standard
Order No.: 5XA5255LF14HGTIN (EAN): 4058352833520
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 1510lm |
| Light distribution | P100008 |
| Control | iQ Street-Remote |
| Pnom | 10W |
| Pnom end service life | 10.4W |
| Pred at 50% lumin. flux | 5.3W |
| Wt. (kg) | 9.9 |
| Price (EUR) | 1432.00 |
Lantern iQ, direct asymmetric extremely wide distribution, P100008, transparent, Power
Order No.: 5XA5255LF14HPGTIN (EAN): 4058352833544
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 4910lm |
| Light distribution | P100008 |
| Control | iQ Street-Remote |
| Pnom | 33.6W |
| Pnom end service life | 35.9W |
| Pred at 50% lumin. flux | 15.3W |
| Wt. (kg) | 9.9 |
| Price (EUR) | 1504.00 |
Lantern iQ, direct asymmetric wide distribution, S120010, transparent, standard
Order No.: 5XA5255KF14HGTIN (EAN): 4058352833483
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 1540lm |
| Light distribution | S120010 |
| Control | iQ Street-Remote |
| Pnom | 10W |
| Pnom end service life | 10.4W |
| Pred at 50% lumin. flux | 5.3W |
| Wt. (kg) | 9.9 |
| Price (EUR) | 1566.30 |
Lantern iQ, direct asymmetric wide distribution, S120010, transparent, Power
Order No.: 5XA5255KF14HPGTIN (EAN): 4058352833506
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 4940lm |
| Light distribution | S120010 |
| Control | iQ Street-Remote |
| Pnom | 33.6W |
| Pnom end service life | 35.9W |
| Pred at 50% lumin. flux | 15.3W |
| Wt. (kg) | 9.9 |
| Price (EUR) | 1504.00 |
Lantern iQ, direct symmetric wide distribution, C120006, transparent, standard
Order No.: 5XA5255RF14HGTIN (EAN): 4058352833667
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 2970lm |
| Light distribution | C120006 |
| Control | iQ Street-Remote |
| Pnom | 18.5W |
| Pnom end service life | 19.7W |
| Pred at 50% lumin. flux | 9.3W |
| Wt. (kg) | 9.9 |
| Price (EUR) | 1723.80 |
Optional accessories
| Order No.: 5XA54000XSGTIN (EAN): 4050737730073 | Show all details |
| Order No.: 5XA54000XSAGTIN (EAN): 4058352161326 | Show all details |
| Order No.: 5XA54000XBSGTIN (EAN): 4050737971445 | Show all details |
| Order No.: 5XA54000XBLGTIN (EAN): 4050737971421 | Show all details |
| Order No.: 5XA54000XBXLGTIN (EAN): 4058352415573 | Show all details |
| Order No.: 5XA54001XSGTIN (EAN): 4050737754895 | Show all details |
| Order No.: 5LA52201XRGTIN (EAN): 4039806232175 | Show all details |
| Order No.: 5NY70062DKGTIN (EAN): 4058352552247 | Show all details |
| Order No.: 5NY52660XG18GTIN (EAN): 4039806215932 | Show all details |
| Order No.: 5NY52650XG18GTIN (EAN): 4039806216694 | Show all details |
| Order No.: 5NY52650XG28GTIN (EAN): 4039806215833 | Show all details |
| Order No.: 5NY52660XN18GTIN (EAN): 4039806216014 | Show all details |
| Order No.: 5NY52650XN18GTIN (EAN): 4039806215857 | Show all details |
| Order No.: 5NY52650XN28GTIN (EAN): 4039806215895 | Show all details |
| Order No.: 5NC54700XGGTIN (EAN): 4039806180513 | Show all details |
