Lantern

Application Configuration & data sheets

Lantern with Module 540 iQ (pre-assembled, incl. connection cable)

Key data

Article mast luminaire
Luminous flux 1510lm to 2970lm
Colour temperature 3000K
Lighting effect direct asymmetric wide distribution; direct asymmetric extremely wide distribution; direct symmetric wide distribution
Light distribution C120006; P100008; S120010
Control iQ Street-Remote; iQ-Street Remote, D4i
Smart Interface above Zhaga
Smart Interface below Zhaga
Protection rating IP65
Insulation class insulation class II (safety insulation)

Special features

Easy installation and low maintenance due to future-oriented modular design for exchangeable LED module and gear tray
Luminous module body as a visual guidance element with decorative day/night time effect
Low energy consumption due to high luminous efficacy and avoidance of overplanning thanks to the patented CLO 2.0 luminous flux tracking
High visual comfort due to uniform illumination and very good glare control – can be further improved with spreader element

Links

To the product page

Configuration & data sheets

Lighting effect

Light distribution

Light distribution

Control

Smart Interface above

Smart Interface below

  • further light colours and connection cable variants on request
  • please order mast reducer separately if required
  • luminaire incl. pre-installed connection cable, l = 5.0m
  • Setting the luminaire with Street-Remote: with the SITECO iQ app on the SITECO iQ handheld (5EA6HBR02) or your own smart phone
  • SITECO offers the SITECO Connect Group Control (230V or 12/24V) product to use the Smart Wire function '10 levels'. A communication module is also available with which remote access is possible and radio clock functionality is provided.

Results

Lantern iQ, direct asymmetric extremely wide distribution, P100008, transparent, standard

Order No.: 5XA5255FF14H000022 GTIN (EAN): 4058352635193
Colour temperatureColour renderingLuminous fluxLight distributionControlSmart InterfacePnomPnom end service lifePred at 50% lumin. fluxWt. (kg)Price (EUR)
3000KCRI > 701510lmP100008iQ Street-Remote 10.5W10.8W5.4W9.01500.80
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Lantern iQ, direct asymmetric wide distribution, S120010, transparent, standard

Order No.: 5XA5255EF14H000022 GTIN (EAN): 4058352635179
Colour temperatureColour renderingLuminous fluxLight distributionControlSmart InterfacePnomPnom end service lifePred at 50% lumin. fluxWt. (kg)Price (EUR)
3000KCRI > 701540lmS120010iQ Street-Remote 10.5W10.8W5.4W9.01500.80
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Lantern iQ, direct symmetric wide distribution, C120006, transparent, standard

Order No.: 5XA5255JF14H000022 GTIN (EAN): 4058352635995
Colour temperatureColour renderingLuminous fluxLight distributionControlSmart InterfacePnomPnom end service lifePred at 50% lumin. fluxWt. (kg)Price (EUR)
3000KCRI > 702970lmC120006iQ Street-Remote 19.3W20.6W9.6W9.01578.90
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Lantern iQ, direct asymmetric wide distribution, S120010, transparent, standard, Z↓

Order No.: 5XA5255EU14H000022 GTIN (EAN): 4058352023945
Colour temperatureColour renderingLuminous fluxLight distributionControlSmart InterfacePnomPnom end service lifePred at 50% lumin. fluxWt. (kg)Price (EUR)
3000KCRI > 701530lmS120010iQ-Street Remote, D4iZ↓10.7W11.1W5.6W9.01630.90
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Lantern iQ, direct asymmetric wide distribution, S120010, transparent, standard, Z↑

Order No.: 5XA5255EV14H000022 GTIN (EAN): 4058352023976
Colour temperatureColour renderingLuminous fluxLight distributionControlSmart InterfacePnomPnom end service lifePred at 50% lumin. fluxWt. (kg)Price (EUR)
3000KCRI > 701530lmS120010iQ-Street Remote, D4iZ↑10.7W11.1W5.6W9.01552.90
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Lantern iQ, direct asymmetric wide distribution, S120010, transparent, standard, Z↑ Z↓

Order No.: 5XA5255EY14H000022 GTIN (EAN): 4058352023983
Colour temperatureColour renderingLuminous fluxLight distributionControlSmart InterfacePnomPnom end service lifePred at 50% lumin. fluxWt. (kg)Price (EUR)
3000KCRI > 701530lmS120010iQ-Street Remote, D4iZ↑ Z↓10.7W11.1W5.6W9.01690.80
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Lantern iQ, direct asymmetric extremely wide distribution, P100008, transparent, standard

Order No.: 5XA5255FF14H000022GTIN (EAN): 4058352635193

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux1510lm
Light distributionP100008
ControliQ Street-Remote
Smart Interface
Pnom10.5W
Pnom end service life10.8W
Pred at 50% lumin. flux5.4W
Wt. (kg)9.0
Price (EUR)1500.80
Show all details

Lantern iQ, direct asymmetric wide distribution, S120010, transparent, standard

Order No.: 5XA5255EF14H000022GTIN (EAN): 4058352635179

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux1540lm
Light distributionS120010
ControliQ Street-Remote
Smart Interface
Pnom10.5W
Pnom end service life10.8W
Pred at 50% lumin. flux5.4W
Wt. (kg)9.0
Price (EUR)1500.80
Show all details

Lantern iQ, direct symmetric wide distribution, C120006, transparent, standard

Order No.: 5XA5255JF14H000022GTIN (EAN): 4058352635995

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux2970lm
Light distributionC120006
ControliQ Street-Remote
Smart Interface
Pnom19.3W
Pnom end service life20.6W
Pred at 50% lumin. flux9.6W
Wt. (kg)9.0
Price (EUR)1578.90
Show all details

Lantern iQ, direct asymmetric wide distribution, S120010, transparent, standard, Z↓

Order No.: 5XA5255EU14H000022GTIN (EAN): 4058352023945

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux1530lm
Light distributionS120010
ControliQ-Street Remote, D4i
Smart InterfaceZ↓
Pnom10.7W
Pnom end service life11.1W
Pred at 50% lumin. flux5.6W
Wt. (kg)9.0
Price (EUR)1630.90
Show all details

Lantern iQ, direct asymmetric wide distribution, S120010, transparent, standard, Z↑

Order No.: 5XA5255EV14H000022GTIN (EAN): 4058352023976

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux1530lm
Light distributionS120010
ControliQ-Street Remote, D4i
Smart InterfaceZ↑
Pnom10.7W
Pnom end service life11.1W
Pred at 50% lumin. flux5.6W
Wt. (kg)9.0
Price (EUR)1552.90
Show all details

Lantern iQ, direct asymmetric wide distribution, S120010, transparent, standard, Z↑ Z↓

Order No.: 5XA5255EY14H000022GTIN (EAN): 4058352023983

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux1530lm
Light distributionS120010
ControliQ-Street Remote, D4i
Smart InterfaceZ↑ Z↓
Pnom10.7W
Pnom end service life11.1W
Pred at 50% lumin. flux5.6W
Wt. (kg)9.0
Price (EUR)1690.80
Show all details

Optional accessories

Articlespreader elementPU1 pc.Wt. (kg)0.2Price (EUR)46.10Order No.: 5XA54000XSGTIN (EAN): 4050737730073Show all details
Articlespreader elementPU1 pc.Wt. (kg)0.2Price (EUR)71.60Order No.: 5XA54000XSAGTIN (EAN): 4058352161326Show all details
Articleshield, rear shieldingPU1 pc.Wt. (kg)0.1Price (EUR)102.50Order No.: 5XA54000XBSGTIN (EAN): 4050737971445Show all details
Articleshield, rear shieldingPU1 pc.Wt. (kg)0.1Price (EUR)115.40Order No.: 5XA54000XBLGTIN (EAN): 4050737971421Show all details
Articleshield, rear shieldingPU1 pc.Wt. (kg)0.5Price (EUR)124.90Order No.: 5XA54000XBXLGTIN (EAN): 4058352415573Show all details
Articledecorative ring, silverPU1 pc.Wt. (kg)0.2Price (EUR)46.10Order No.: 5XA54001XSGTIN (EAN): 4050737754895Show all details
Articlereducer, spigot size: 76/60mmPU1 pc.Wt. (kg)0.1Price (EUR)33.90Order No.: 5LA52201XRGTIN (EAN): 4039806232175Show all details
Articlecable junction box, 2x E14, for 3 cables to 5x 16mm²PU1 pc.Wt. (kg)0.8Price (EUR)189.70Order No.: 5NY70062DKGTIN (EAN): 4058352552247Show all details
Articlewall bracket, rocker-type, single, DB 702S, a= 600mmPU1 pc.Wt. (kg)7.4Price (EUR)809.30Order No.: 5NY52660XG18GTIN (EAN): 4039806215932Show all details
Articlemast arm, rocker-type, single, DB 702S, a= 600mm, d_a= 76mmPU1 pc.Wt. (kg)9.5Price (EUR)992.20Order No.: 5NY52650XG18GTIN (EAN): 4039806216694Show all details
Articlemast arm, rocker-type, twin, DB 702S, a= 600mm, d_a= 76mmPU1 pc.Wt. (kg)13.8Price (EUR)1432.80Order No.: 5NY52650XG28GTIN (EAN): 4039806215833Show all details
Articlewall bracket, rail-type, single, DB 702S, a= 600mmPU1 pc.Wt. (kg)7.9Price (EUR)752.30Order No.: 5NY52660XN18GTIN (EAN): 4039806216014Show all details
Articlemast arm, rail-type, single, DB 702S, a= 600mm, d_a= 76mmPU1 pc.Wt. (kg)9.8Price (EUR)869.70Order No.: 5NY52650XN18GTIN (EAN): 4039806215857Show all details
Articlemast arm, rail-type, twin, DB 702S, a= 600mm, d_a= 76mmPU1 pc.Wt. (kg)15.9Price (EUR)1229.40Order No.: 5NY52650XN28GTIN (EAN): 4039806215895Show all details
Articlecover, PMMA, transparent, ø= 185mmPU1 pc.Wt. (kg)2.0Price (EUR)261.40Order No.: 5NC54700XGGTIN (EAN): 4039806180513Show all details
