Product selection
Sirius 500
Special features
Highly efficient thanks to silver reflectors (ECO RS) or glass lenses (AREA PL52) for low energy consumption and operating costs
Extremely powerful with up to 66,000lm with a long service life of up to 100,000 hours and minimal luminous flux degradation for the use of high maintenance factors
With a TLCI value of 96 at 5700K for true-to-life colour rendering and minimum post-editing work for broadcasters
DALI ECG integrated into housing, with the cable already pre-assembled with a plug-socket system for time-saving assembly
Configuration & data sheets
- on request also available as RGBW version
Results
Sirius 500, luminaire head, AREA-PL52, asymmetric distribution
Order No.: 5XA7100W5ZS00100XX GTIN (EAN): 4058352448861
| Colour temperature | Colour rendering | TLCI | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|---|
| 5700K | CRI > 95 | TLCI ≥ 96 | 55860lm | 493W | 113lm/W | power reduction, DALI | 16.0 |
Sirius 500, luminaire head, AREA-PL52, asymmetric distribution
Order No.: 5XA7100W4ZS00101XX GTIN (EAN): 4058352448847
| Colour temperature | Colour rendering | TLCI | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|---|
| 5000K | CRI > 90 | TLCI ≥ 87 | 59785lm | 493W | 121lm/W | power reduction, DALI | 16.0 |
Sirius 500, luminaire head, AREA-PL52, asymmetric distribution
Order No.: 5XA7100W5ZS00100XXGTIN (EAN): 4058352448861
| Colour temperature | 5700K |
|---|---|
| Colour rendering | CRI > 95 |
| TLCI | TLCI ≥ 96 |
| Luminous flux | 55860lm |
| Connected load | 493W |
| Luminous efficacy | 113lm/W |
| Control | power reduction, DALI |
| Wt. (kg) | 16.0 |
Sirius 500, luminaire head, AREA-PL52, asymmetric distribution
Order No.: 5XA7100W4ZS00101XXGTIN (EAN): 4058352448847
| Colour temperature | 5000K |
|---|---|
| Colour rendering | CRI > 90 |
| TLCI | TLCI ≥ 87 |
| Luminous flux | 59785lm |
| Connected load | 493W |
| Luminous efficacy | 121lm/W |
| Control | power reduction, DALI |
| Wt. (kg) | 16.0 |
Mandatory accessories
| Order No.: 5XA71000XFGTIN (EAN): 4058352357774 | Show all details |
