City-Light

ReferencesApplication Product selection Configuration & data sheets

References

Villa am See, Switzerland
Products: mast luminaires, CL 31 Bollard
learn more

City-Light Plus with Module 540 iQ (as single components)

Key data

Article mast luminaire
Luminous flux 1440lm to 4710lm
Colour temperature 2200K; 2700K; 3000K; 4000K
Lighting effect direct asymmetric wide distribution; direct asymmetric extremely wide distribution; direct symmetric wide distribution
Light distribution C120007; P100009; S120011
Control iQ Street-Remote
Protection rating IP65
Insulation class insulation class II (safety insulation)

Special features

Easy installation and low maintenance due to future-oriented modular design for exchangeable LED module and gear tray
Luminous module body as a visual guidance element with decorative day/night time effect
Low energy consumption due to high luminous efficacy and avoidance of overplanning thanks to the patented CLO 2.0 luminous flux tracking
High visual comfort due to uniform illumination and very good glare control – can be further improved with spreader element

Links

To the product page

Configuration & data sheets

Lighting effect

Light distribution

Light distribution

Colour temperature

Equipment

  • please order mast reducer separately if required
  • Setting the luminaire with Street-Remote: with the SITECO iQ app on the SITECO iQ handheld (5EA6HBR02) or your own smart phone
  • SITECO offers the SITECO Connect Group Control (230V or 12/24V) product to use the Smart Wire function '10 levels'. A communication module is also available with which remote access is possible and radio clock functionality is provided.
  • Smart Interface luminaires currently without iQ functionality

Results

City-Light Plus iQ, direct asymmetric extremely wide distribution, P100009, transparent, standard

Order No.: 5XA5275BF14H GTIN (EAN): 4058352835166
Colour temperatureColour renderingLuminous fluxLight distributionControlPnomPnom end service lifePred at 50% lumin. fluxWt. (kg)
2200KCRI > 701440lmP100009iQ Street-Remote12.9W13.3W6.4W11.0
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

City-Light Plus iQ, direct asymmetric extremely wide distribution, P100009, transparent, Power

Order No.: 5XA5275BF14HP GTIN (EAN): 4058352835173
Colour temperatureColour renderingLuminous fluxLight distributionControlPnomPnom end service lifePred at 50% lumin. fluxWt. (kg)
2200KCRI > 703710lmP100009iQ Street-Remote33.6W35.9W15.2W11.0
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

City-Light Plus iQ, direct asymmetric wide distribution, S120011, transparent, standard

Order No.: 5XA5275AF14H GTIN (EAN): 4058352835111
Colour temperatureColour renderingLuminous fluxLight distributionControlPnomPnom end service lifePred at 50% lumin. fluxWt. (kg)
2200KCRI > 701470lmS120011iQ Street-Remote12.9W13.3W6.4W11.0
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

City-Light Plus iQ, direct asymmetric wide distribution, S120011, transparent, Power

Order No.: 5XA5275AF14HP GTIN (EAN): 4058352835135
Colour temperatureColour renderingLuminous fluxLight distributionControlPnomPnom end service lifePred at 50% lumin. fluxWt. (kg)
2200KCRI > 703730lmS120011iQ Street-Remote33.6W35.9W15.2W11.0
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

City-Light Plus iQ, direct symmetric wide distribution, C120007, transparent, standard

Order No.: 5XA5275CF14H GTIN (EAN): 4058352835197
Colour temperatureColour renderingLuminous fluxLight distributionControlPnomPnom end service lifePred at 50% lumin. fluxWt. (kg)
2200KCRI > 702840lmC120007iQ Street-Remote23.9W25.5W11.5W11.0
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

City-Light Plus iQ, direct asymmetric extremely wide distribution, P100009, transparent, standard

Order No.: 5XA5275NF14H GTIN (EAN): 4058352835371
Colour temperatureColour renderingLuminous fluxLight distributionControlPnomPnom end service lifePred at 50% lumin. fluxWt. (kg)
2700KCRI > 701440lmP100009iQ Street-Remote11.8W12.1W6W11.0
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

City-Light Plus iQ, direct asymmetric extremely wide distribution, P100009, transparent, Power

Order No.: 5XA5275NF14HP GTIN (EAN): 4058352835395
Colour temperatureColour renderingLuminous fluxLight distributionControlPnomPnom end service lifePred at 50% lumin. fluxWt. (kg)
2700KCRI > 704020lmP100009iQ Street-Remote33.6W35.9W15.2W11.0
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

City-Light Plus iQ, direct asymmetric wide distribution, S120011, transparent, standard

Order No.: 5XA5275MF14H GTIN (EAN): 4058352835340
Colour temperatureColour renderingLuminous fluxLight distributionControlPnomPnom end service lifePred at 50% lumin. fluxWt. (kg)
2700KCRI > 701470lmS120011iQ Street-Remote11.8W12.1W6W11.0
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

City-Light Plus iQ, direct asymmetric wide distribution, S120011, transparent, Power

Order No.: 5XA5275MF14HP GTIN (EAN): 4058352835357
Colour temperatureColour renderingLuminous fluxLight distributionControlPnomPnom end service lifePred at 50% lumin. fluxWt. (kg)
2700KCRI > 704040lmS120011iQ Street-Remote33.6W35.9W15.2W11.0
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

City-Light Plus iQ, direct symmetric wide distribution, C120007, transparent, standard

Order No.: 5XA5275OF14H GTIN (EAN): 4058352835418
Colour temperatureColour renderingLuminous fluxLight distributionControlPnomPnom end service lifePred at 50% lumin. fluxWt. (kg)
2700KCRI > 702840lmC120007iQ Street-Remote21.8W23.2W10.7W11.0
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

City-Light Plus iQ, direct asymmetric extremely wide distribution, P100009, transparent, standard

Order No.: 5XA5275FF14H GTIN (EAN): 4058352636152
Colour temperatureColour renderingLuminous fluxLight distributionControlPnomPnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 701440lmP100009iQ Street-Remote10.5W10.8W5.4W11.0
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

City-Light Plus iQ, direct asymmetric extremely wide distribution, P100009, transparent, Power

Order No.: 5XA5275FF14HP GTIN (EAN): 4058352835234
Colour temperatureColour renderingLuminous fluxLight distributionControlPnomPnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 704480lmP100009iQ Street-Remote33.6W35.9W15.2W11.0
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

City-Light Plus iQ, direct asymmetric wide distribution, S120011, transparent, standard

Order No.: 5XA5275EF14H GTIN (EAN): 4058352636138
Colour temperatureColour renderingLuminous fluxLight distributionControlPnomPnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 701470lmS120011iQ Street-Remote10.5W10.8W5.4W11.0
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

City-Light Plus iQ, direct asymmetric wide distribution, S120011, transparent, Power

Order No.: 5XA5275EF14HP GTIN (EAN): 4058352835210
Colour temperatureColour renderingLuminous fluxLight distributionControlPnomPnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 704510lmS120011iQ Street-Remote33.6W35.9W15.2W11.0
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

City-Light Plus iQ, direct symmetric wide distribution, C120007, transparent, standard

Order No.: 5XA5275JF14H GTIN (EAN): 4058352636190
Colour temperatureColour renderingLuminous fluxLight distributionControlPnomPnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 702830lmC120007iQ Street-Remote19.3W20.6W9.6W11.0
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

City-Light Plus iQ, direct asymmetric extremely wide distribution, P100009, transparent, standard

Order No.: 5XA5275LF14H GTIN (EAN): 4058352835296
Colour temperatureColour renderingLuminous fluxLight distributionControlPnomPnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 701440lmP100009iQ Street-Remote10W10.4W5.3W11.0
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

City-Light Plus iQ, direct asymmetric extremely wide distribution, P100009, transparent, Power

Order No.: 5XA5275LF14HP GTIN (EAN): 4058352835319
Colour temperatureColour renderingLuminous fluxLight distributionControlPnomPnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 704680lmP100009iQ Street-Remote33.6W35.9W15.3W11.0
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

City-Light Plus iQ, direct asymmetric wide distribution, S120011, transparent, standard

Order No.: 5XA5275KF14H GTIN (EAN): 4058352835258
Colour temperatureColour renderingLuminous fluxLight distributionControlPnomPnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 701470lmS120011iQ Street-Remote10W10.4W5.3W11.0
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

City-Light Plus iQ, direct asymmetric wide distribution, S120011, transparent, Power

Order No.: 5XA5275KF14HP GTIN (EAN): 4058352835272
Colour temperatureColour renderingLuminous fluxLight distributionControlPnomPnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 704710lmS120011iQ Street-Remote33.6W35.9W15.3W11.0
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

City-Light Plus iQ, direct symmetric wide distribution, C120007, transparent, standard

Order No.: 5XA5275RF14H GTIN (EAN): 4058352835432
Colour temperatureColour renderingLuminous fluxLight distributionControlPnomPnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 702840lmC120007iQ Street-Remote18.5W19.7W9.3W11.0
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

City-Light Plus iQ, direct asymmetric extremely wide distribution, P100009, transparent, standard

Order No.: 5XA5275BF14HGTIN (EAN): 4058352835166

Colour temperature2200K
Colour renderingCRI > 70
Luminous flux1440lm
Light distributionP100009
ControliQ Street-Remote
Pnom12.9W
Pnom end service life13.3W
Pred at 50% lumin. flux6.4W
Wt. (kg)11.0
Show all details

City-Light Plus iQ, direct asymmetric extremely wide distribution, P100009, transparent, Power

Order No.: 5XA5275BF14HPGTIN (EAN): 4058352835173

Colour temperature2200K
Colour renderingCRI > 70
Luminous flux3710lm
Light distributionP100009
ControliQ Street-Remote
Pnom33.6W
Pnom end service life35.9W
Pred at 50% lumin. flux15.2W
Wt. (kg)11.0
Show all details

City-Light Plus iQ, direct asymmetric wide distribution, S120011, transparent, standard

Order No.: 5XA5275AF14HGTIN (EAN): 4058352835111

Colour temperature2200K
Colour renderingCRI > 70
Luminous flux1470lm
Light distributionS120011
ControliQ Street-Remote
Pnom12.9W
Pnom end service life13.3W
Pred at 50% lumin. flux6.4W
Wt. (kg)11.0
Show all details

City-Light Plus iQ, direct asymmetric wide distribution, S120011, transparent, Power

Order No.: 5XA5275AF14HPGTIN (EAN): 4058352835135

Colour temperature2200K
Colour renderingCRI > 70
Luminous flux3730lm
Light distributionS120011
ControliQ Street-Remote
Pnom33.6W
Pnom end service life35.9W
Pred at 50% lumin. flux15.2W
Wt. (kg)11.0
Show all details

City-Light Plus iQ, direct symmetric wide distribution, C120007, transparent, standard

Order No.: 5XA5275CF14HGTIN (EAN): 4058352835197

Colour temperature2200K
Colour renderingCRI > 70
Luminous flux2840lm
Light distributionC120007
ControliQ Street-Remote
Pnom23.9W
Pnom end service life25.5W
Pred at 50% lumin. flux11.5W
Wt. (kg)11.0
Show all details

City-Light Plus iQ, direct asymmetric extremely wide distribution, P100009, transparent, standard

Order No.: 5XA5275NF14HGTIN (EAN): 4058352835371

Colour temperature2700K
Colour renderingCRI > 70
Luminous flux1440lm
Light distributionP100009
ControliQ Street-Remote
Pnom11.8W
Pnom end service life12.1W
Pred at 50% lumin. flux6W
Wt. (kg)11.0
Show all details

City-Light Plus iQ, direct asymmetric extremely wide distribution, P100009, transparent, Power

Order No.: 5XA5275NF14HPGTIN (EAN): 4058352835395

Colour temperature2700K
Colour renderingCRI > 70
Luminous flux4020lm
Light distributionP100009
ControliQ Street-Remote
Pnom33.6W
Pnom end service life35.9W
Pred at 50% lumin. flux15.2W
Wt. (kg)11.0
Show all details

City-Light Plus iQ, direct asymmetric wide distribution, S120011, transparent, standard

Order No.: 5XA5275MF14HGTIN (EAN): 4058352835340

Colour temperature2700K
Colour renderingCRI > 70
Luminous flux1470lm
Light distributionS120011
ControliQ Street-Remote
Pnom11.8W
Pnom end service life12.1W
Pred at 50% lumin. flux6W
Wt. (kg)11.0
Show all details

City-Light Plus iQ, direct asymmetric wide distribution, S120011, transparent, Power

Order No.: 5XA5275MF14HPGTIN (EAN): 4058352835357

Colour temperature2700K
Colour renderingCRI > 70
Luminous flux4040lm
Light distributionS120011
ControliQ Street-Remote
Pnom33.6W
Pnom end service life35.9W
Pred at 50% lumin. flux15.2W
Wt. (kg)11.0
Show all details

City-Light Plus iQ, direct symmetric wide distribution, C120007, transparent, standard

Order No.: 5XA5275OF14HGTIN (EAN): 4058352835418

Colour temperature2700K
Colour renderingCRI > 70
Luminous flux2840lm
Light distributionC120007
ControliQ Street-Remote
Pnom21.8W
Pnom end service life23.2W
Pred at 50% lumin. flux10.7W
Wt. (kg)11.0
Show all details

City-Light Plus iQ, direct asymmetric extremely wide distribution, P100009, transparent, standard

Order No.: 5XA5275FF14HGTIN (EAN): 4058352636152

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux1440lm
Light distributionP100009
ControliQ Street-Remote
Pnom10.5W
Pnom end service life10.8W
Pred at 50% lumin. flux5.4W
Wt. (kg)11.0
Show all details

City-Light Plus iQ, direct asymmetric extremely wide distribution, P100009, transparent, Power

Order No.: 5XA5275FF14HPGTIN (EAN): 4058352835234

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux4480lm
Light distributionP100009
ControliQ Street-Remote
Pnom33.6W
Pnom end service life35.9W
Pred at 50% lumin. flux15.2W
Wt. (kg)11.0
Show all details

City-Light Plus iQ, direct asymmetric wide distribution, S120011, transparent, standard

Order No.: 5XA5275EF14HGTIN (EAN): 4058352636138

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux1470lm
Light distributionS120011
ControliQ Street-Remote
Pnom10.5W
Pnom end service life10.8W
Pred at 50% lumin. flux5.4W
Wt. (kg)11.0
Show all details

City-Light Plus iQ, direct asymmetric wide distribution, S120011, transparent, Power

Order No.: 5XA5275EF14HPGTIN (EAN): 4058352835210

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux4510lm
Light distributionS120011
ControliQ Street-Remote
Pnom33.6W
Pnom end service life35.9W
Pred at 50% lumin. flux15.2W
Wt. (kg)11.0
Show all details

City-Light Plus iQ, direct symmetric wide distribution, C120007, transparent, standard

Order No.: 5XA5275JF14HGTIN (EAN): 4058352636190

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux2830lm
Light distributionC120007
ControliQ Street-Remote
Pnom19.3W
Pnom end service life20.6W
Pred at 50% lumin. flux9.6W
Wt. (kg)11.0
Show all details

City-Light Plus iQ, direct asymmetric extremely wide distribution, P100009, transparent, standard

Order No.: 5XA5275LF14HGTIN (EAN): 4058352835296

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux1440lm
Light distributionP100009
ControliQ Street-Remote
Pnom10W
Pnom end service life10.4W
Pred at 50% lumin. flux5.3W
Wt. (kg)11.0
Show all details

City-Light Plus iQ, direct asymmetric extremely wide distribution, P100009, transparent, Power

Order No.: 5XA5275LF14HPGTIN (EAN): 4058352835319

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux4680lm
Light distributionP100009
ControliQ Street-Remote
Pnom33.6W
Pnom end service life35.9W
Pred at 50% lumin. flux15.3W
Wt. (kg)11.0
Show all details

City-Light Plus iQ, direct asymmetric wide distribution, S120011, transparent, standard

Order No.: 5XA5275KF14HGTIN (EAN): 4058352835258

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux1470lm
Light distributionS120011
ControliQ Street-Remote
Pnom10W
Pnom end service life10.4W
Pred at 50% lumin. flux5.3W
Wt. (kg)11.0
Show all details

City-Light Plus iQ, direct asymmetric wide distribution, S120011, transparent, Power

Order No.: 5XA5275KF14HPGTIN (EAN): 4058352835272

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux4710lm
Light distributionS120011
ControliQ Street-Remote
Pnom33.6W
Pnom end service life35.9W
Pred at 50% lumin. flux15.3W
Wt. (kg)11.0
Show all details

City-Light Plus iQ, direct symmetric wide distribution, C120007, transparent, standard

Order No.: 5XA5275RF14HGTIN (EAN): 4058352835432

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux2840lm
Light distributionC120007
ControliQ Street-Remote
Pnom18.5W
Pnom end service life19.7W
Pred at 50% lumin. flux9.3W
Wt. (kg)11.0
Show all details

Optional accessories

Articlespreader elementPU1 pc.Wt. (kg)0.2Order No.: 5XA54000XSGTIN (EAN): 4050737730073Show all details
Articlespreader elementPU1 pc.Wt. (kg)0.2Order No.: 5XA54000XSAGTIN (EAN): 4058352161326Show all details
Articleshield, rear shieldingPU1 pc.Wt. (kg)0.1Order No.: 5XA54000XBSGTIN (EAN): 4050737971445Show all details
Articleshield, rear shieldingPU1 pc.Wt. (kg)0.1Order No.: 5XA54000XBLGTIN (EAN): 4050737971421Show all details
Articleshield, rear shieldingPU1 pc.Wt. (kg)0.5Order No.: 5XA54000XBXLGTIN (EAN): 4058352415573Show all details
Articledecorative ring, silverPU1 pc.Wt. (kg)0.2Order No.: 5XA54001XSGTIN (EAN): 4050737754895Show all details
Articlereducer, spigot size: 76/60mmPU1 pc.Wt. (kg)0.1Order No.: 5LA52201XRGTIN (EAN): 4039806232175Show all details
Articlecable junction box, 2x E14, for 3 cables to 5x 16mm²PU1 pc.Wt. (kg)0.8Order No.: 5NY70062DKGTIN (EAN): 4058352552247Show all details
Articlewall bracket, rocker-type, single, DB 702S, a= 600mmPU1 pc.Wt. (kg)7.4Order No.: 5NY52660XG18GTIN (EAN): 4039806215932Show all details
Articlemast arm, rocker-type, single, DB 702S, a= 600mm, d_a= 76mmPU1 pc.Wt. (kg)9.5Order No.: 5NY52650XG18GTIN (EAN): 4039806216694Show all details
Articlemast arm, rocker-type, twin, DB 702S, a= 600mm, d_a= 76mmPU1 pc.Wt. (kg)13.8Order No.: 5NY52650XG28GTIN (EAN): 4039806215833Show all details
Articlewall bracket, rail-type, single, DB 702S, a= 600mmPU1 pc.Wt. (kg)7.9Order No.: 5NY52660XN18GTIN (EAN): 4039806216014Show all details
Articlemast arm, rail-type, single, DB 702S, a= 600mm, d_a= 76mmPU1 pc.Wt. (kg)9.8Order No.: 5NY52650XN18GTIN (EAN): 4039806215857Show all details
Articlemast arm, rail-type, twin, DB 702S, a= 600mm, d_a= 76mmPU1 pc.Wt. (kg)15.9Order No.: 5NY52650XN28GTIN (EAN): 4039806215895Show all details
Articlecover, PMMA, transparent, ø= 200mmPU1 pc.Wt. (kg)1.3Order No.: 5NA54900XGGTIN (EAN): 4039806059666Show all details
Articlecover, PMMA, frosted, ø= 200mmPU1 pc.Wt. (kg)1.2Order No.: 5NA54903XGGTIN (EAN): 4039806210357Show all details
