Monsun

Family Product selection Configuration & data sheets

Family

Monsun 11 High-end. Outstanding lighting technology and high-quality design meet maximum variety, efficiency (200 lm/W) and service life (100,000 hours)

Monsun 21 Performance. Excellent efficiency (188lm/W) and service life (75,000 hours)

Monsun 31 Standard. Proven technology for standard applications with excellent efficiency (165lm/W) and service life (70,000 hours)

Monsun 31 Tube Tube solution. Highest protection class IP67/IP69K with excellent efficiency (160lm/W) and service life (50,000 hours)

Monsun 41 Basic. Practical, efficient (150lm/W) and durable (50,000 hours)

Monsun Ex Ex solution. For use in EX zones 1/21 and 2/22

Monsun enclosures

Product selection

Monsun 31 Tube

Monsun 31 Tube

Key data

Article tubular luminaire
Lighting effect direct symmetric diffuse distribution
Net luminous flux 6500lm to 10000lm
Colour temperature 4000K
Control ON/OFF; DALI 2
Cover PMMA
Protection rating IP67/IP69K
Insulation class insulation class I (protective earthing)
Impact resistance IK07
IFS corresponds to IFS (International Featured Standards) requirements for safety and quality in the food industry

Special features

Highest degree of protection IP67 / IP69K against hot water jets from the high-pressure cleaner
Resistant to harmful gases with a short sealing system
Tube of PMMA with end caps of stainless steel (V4A)
With through-wiring and external terminal for individual connection options

Configuration & data sheets

Rated luminous flux (lm)

Control

Through-wiring

Length (mm)

Results

Monsun 31 Tube, diffuse distribution, ON/OFF, PMMA

Order No.: 51FT107N460A GTIN (EAN): 4058352701225
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlThrough-wiringtaImpact resistanceL (mm)Wt. (kg)
4000KCRI > 806500lm40W160lm/WON/OFF3x 1.5mm²-20..+40°CIK0715601.8
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Monsun 31 Tube, diffuse distribution, ON/OFF, PMMA

Order No.: 51FT107N480A GTIN (EAN): 4058352701256
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlThrough-wiringtaImpact resistanceL (mm)Wt. (kg)
4000KCRI > 808000lm50W160lm/WON/OFF3x 1.5mm²-20..+40°CIK0715601.8
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Monsun 31 Tube, diffuse distribution, ON/OFF, PMMA

Order No.: 51FT107N4A0A GTIN (EAN): 4058352701287
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlThrough-wiringtaImpact resistanceL (mm)Wt. (kg)
4000KCRI > 8010000lm58W160lm/WON/OFF3x 1.5mm²-20..+40°CIK0715601.8
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Monsun 31 Tube, diffuse distribution, DALI 2, PMMA

Order No.: 51FT10DN460A GTIN (EAN): 4058352701317
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlThrough-wiringtaImpact resistanceL (mm)Wt. (kg)
4000KCRI > 806500lm40W160lm/WDALI 25x 1.5mm²-20..+40°CIK0715701.9
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Monsun 31 Tube, diffuse distribution, DALI 2, PMMA

Order No.: 51FT10DN480A GTIN (EAN): 4058352701362
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlThrough-wiringtaImpact resistanceL (mm)Wt. (kg)
4000KCRI > 808000lm50W160lm/WDALI 25x 1.5mm²-20..+40°CIK0715701.9
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Monsun 31 Tube, diffuse distribution, DALI 2, PMMA

Order No.: 51FT10DN4A0A GTIN (EAN): 4058352701379
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlThrough-wiringtaImpact resistanceL (mm)Wt. (kg)
4000KCRI > 8010000lm58W160lm/WDALI 25x 1.5mm²-20..+40°CIK0715701.9
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Monsun 31 Tube, diffuse distribution, ON/OFF, PMMA

Order No.: 51FT107N460AGTIN (EAN): 4058352701225

Colour temperature4000K
Colour renderingCRI > 80
Luminous flux6500lm
Connected load40W
Luminous efficacy160lm/W
ControlON/OFF
Through-wiring3x 1.5mm²
ta-20..+40°C
Impact resistanceIK07
L (mm)1560
Wt. (kg)1.8
Show all details

Monsun 31 Tube, diffuse distribution, ON/OFF, PMMA

Order No.: 51FT107N480AGTIN (EAN): 4058352701256

Colour temperature4000K
Colour renderingCRI > 80
Luminous flux8000lm
Connected load50W
Luminous efficacy160lm/W
ControlON/OFF
Through-wiring3x 1.5mm²
ta-20..+40°C
Impact resistanceIK07
L (mm)1560
Wt. (kg)1.8
Show all details

Monsun 31 Tube, diffuse distribution, ON/OFF, PMMA

Order No.: 51FT107N4A0AGTIN (EAN): 4058352701287

Colour temperature4000K
Colour renderingCRI > 80
Luminous flux10000lm
Connected load58W
Luminous efficacy160lm/W
ControlON/OFF
Through-wiring3x 1.5mm²
ta-20..+40°C
Impact resistanceIK07
L (mm)1560
Wt. (kg)1.8
Show all details

Monsun 31 Tube, diffuse distribution, DALI 2, PMMA

Order No.: 51FT10DN460AGTIN (EAN): 4058352701317

Colour temperature4000K
Colour renderingCRI > 80
Luminous flux6500lm
Connected load40W
Luminous efficacy160lm/W
ControlDALI 2
Through-wiring5x 1.5mm²
ta-20..+40°C
Impact resistanceIK07
L (mm)1570
Wt. (kg)1.9
Show all details

Monsun 31 Tube, diffuse distribution, DALI 2, PMMA

Order No.: 51FT10DN480AGTIN (EAN): 4058352701362

Colour temperature4000K
Colour renderingCRI > 80
Luminous flux8000lm
Connected load50W
Luminous efficacy160lm/W
ControlDALI 2
Through-wiring5x 1.5mm²
ta-20..+40°C
Impact resistanceIK07
L (mm)1570
Wt. (kg)1.9
Show all details

Monsun 31 Tube, diffuse distribution, DALI 2, PMMA

Order No.: 51FT10DN4A0AGTIN (EAN): 4058352701379

Colour temperature4000K
Colour renderingCRI > 80
Luminous flux10000lm
Connected load58W
Luminous efficacy160lm/W
ControlDALI 2
Through-wiring5x 1.5mm²
ta-20..+40°C
Impact resistanceIK07
L (mm)1570
Wt. (kg)1.9
Show all details
