SITECO

spot

Family Product selection Configuration & data sheets

Product selection

Spot 21

Spot 21

Special features

High lumen package
Three housing colours
Can be preset to individual needs thanks to the multi-lumen function for various luminous flux packages
Lighting control via DALI-2 or as ON/OFF version available
Reflector can be replaced without tools if necessary and can therefore be adapted to changing requirements
Optionally with a specific colour temperature for the optimal presentation of meat and sausage products

Configuration & data sheets

Beam angle

Colour temperature

Light colour

UGR

Rated luminous flux (lm)

Control

Operating ambient temperature

D (mm)

Colour

Results

Spot 21 standard, wide distribution, ON/OFF, Ø90, traffic white (RAL 9016)

Order No.: 51SE147AD3B GTIN (EAN): 4058352609675
Colour temperatureColour renderingBeam angleLuminous fluxConnected loadLuminous efficacyControlDimension (mm)ColourWt. (kg)
4000KCRI > 90wide distribution2700lm ON/OFFØ90traffic white (RAL 9016)0.7
Show all details
Tender textData sheet (PDF, full)Complete download list

Spot 21 standard, 32°, DALI Multilumen, Ø105, metallic grey (RAL 9006)

Order No.: 51SE63EBD5B GTIN (EAN): 4058352767894
Colour temperatureColour renderingBeam angleLuminous fluxConnected loadLuminous efficacyControlDimension (mm)ColourWt. (kg)
4000KCRI > 9032°5200lm40W129lm/WDALI MultilumenØ105metallic grey (RAL 9006)1.1
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Spot 21 standard, wide distribution, ON/OFF, Ø90, white

Order No.: 51SE147AD3A GTIN (EAN): 4058352520901
Colour temperatureColour renderingBeam angleLuminous fluxConnected loadLuminous efficacyControlDimension (mm)ColourWt. (kg)
4000KCRI > 85wide distribution2700lm ON/OFFØ90white1.0
Show all details
Tender textData sheet (PDF, full)Complete download list

Spot 21 standard, medium distribution, ON/OFF, Ø105, traffic white (RAL 9016)

Order No.: 51SE137BB3B GTIN (EAN): 4058352609668
Colour temperatureColour renderingBeam angleLuminous fluxConnected loadLuminous efficacyControlDimension (mm)ColourWt. (kg)
3000KCRI > 90medium distribution2700lm ON/OFFØ105traffic white (RAL 9016)0.8
Show all details
Tender textData sheet (PDF, full)Complete download list

Spot 21 standard, wide distribution, ON/OFF, Ø105, traffic white (RAL 9016)

Order No.: 51SE147BM2B GTIN (EAN): 4058352609712
Colour temperatureColour renderingBeam angleLuminous fluxConnected loadLuminous efficacyControlDimension (mm)ColourWt. (kg)
for meat products wide distribution2000lm ON/OFFØ105traffic white (RAL 9016)0.8
Show all details
Tender textData sheet (PDF, full)Complete download list

Spot 21 standard, 32°, ON/OFF Multilumen, Ø105, traffic white (RAL 9016)

Order No.: 51SE13MBD5B GTIN (EAN): 4058352716632
Colour temperatureColour renderingBeam angleLuminous fluxConnected loadLuminous efficacyControlDimension (mm)ColourWt. (kg)
4000KCRI > 9032°5300lm40W134lm/WON/OFF MultilumenØ105traffic white (RAL 9016)1.1
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Spot 21 standard, wide distribution, ON/OFF, Ø105, traffic white (RAL 9016)

Order No.: 51SE147BB4B GTIN (EAN): 4058352631898
Colour temperatureColour renderingBeam angleLuminous fluxConnected loadLuminous efficacyControlDimension (mm)ColourWt. (kg)
3000KCRI > 90wide distribution3900lm ON/OFFØ105traffic white (RAL 9016)0.8
Show all details
Tender textData sheet (PDF, full)Complete download list

Spot 21 standard, wide distribution, ON/OFF, Ø105, traffic white (RAL 9016)

Order No.: 51SE147BD4B GTIN (EAN): 4058352609705
Colour temperatureColour renderingBeam angleLuminous fluxConnected loadLuminous efficacyControlDimension (mm)ColourWt. (kg)
4000KCRI > 90wide distribution3900lm ON/OFFØ105traffic white (RAL 9016)0.8
Show all details
Tender textData sheet (PDF, full)Complete download list

Spot 21 standard, wide distribution, ON/OFF, Ø105, traffic white (RAL 9016)

Order No.: 51SE147BA4B GTIN (EAN): 4058352609699
Colour temperatureColour renderingBeam angleLuminous fluxConnected loadLuminous efficacyControlDimension (mm)ColourWt. (kg)
2700KCRI > 90wide distribution3900lm ON/OFFØ105traffic white (RAL 9016)0.8
Show all details
Tender textData sheet (PDF, full)Complete download list

Spot 21 standard, wide distribution, ON/OFF, Ø90, traffic white (RAL 9016)

Order No.: 51SE147AD3BGTIN (EAN): 4058352609675

Colour temperature4000K
Colour renderingCRI > 90
Beam anglewide distribution
Luminous flux2700lm
Connected load
Luminous efficacy
ControlON/OFF
Dimension (mm)Ø90
Colourtraffic white (RAL 9016)
Wt. (kg)0.7
Show all details

Spot 21 standard, 32°, DALI Multilumen, Ø105, metallic grey (RAL 9006)

Order No.: 51SE63EBD5BGTIN (EAN): 4058352767894

Colour temperature4000K
Colour renderingCRI > 90
Beam angle32°
Luminous flux5200lm
Connected load40W
Luminous efficacy129lm/W
ControlDALI Multilumen
Dimension (mm)Ø105
Colourmetallic grey (RAL 9006)
Wt. (kg)1.1
Show all details

Spot 21 standard, wide distribution, ON/OFF, Ø90, white

Order No.: 51SE147AD3AGTIN (EAN): 4058352520901

Colour temperature4000K
Colour renderingCRI > 85
Beam anglewide distribution
Luminous flux2700lm
Connected load
Luminous efficacy
ControlON/OFF
Dimension (mm)Ø90
Colourwhite
Wt. (kg)1.0
Show all details

Spot 21 standard, medium distribution, ON/OFF, Ø105, traffic white (RAL 9016)

Order No.: 51SE137BB3BGTIN (EAN): 4058352609668

Colour temperature3000K
Colour renderingCRI > 90
Beam anglemedium distribution
Luminous flux2700lm
Connected load
Luminous efficacy
ControlON/OFF
Dimension (mm)Ø105
Colourtraffic white (RAL 9016)
Wt. (kg)0.8
Show all details

Spot 21 standard, wide distribution, ON/OFF, Ø105, traffic white (RAL 9016)

Order No.: 51SE147BM2BGTIN (EAN): 4058352609712

Colour temperaturefor meat products
Colour rendering
Beam anglewide distribution
Luminous flux2000lm
Connected load
Luminous efficacy
ControlON/OFF
Dimension (mm)Ø105
Colourtraffic white (RAL 9016)
Wt. (kg)0.8
Show all details

Spot 21 standard, 32°, ON/OFF Multilumen, Ø105, traffic white (RAL 9016)

Order No.: 51SE13MBD5BGTIN (EAN): 4058352716632

Colour temperature4000K
Colour renderingCRI > 90
Beam angle32°
Luminous flux5300lm
Connected load40W
Luminous efficacy134lm/W
ControlON/OFF Multilumen
Dimension (mm)Ø105
Colourtraffic white (RAL 9016)
Wt. (kg)1.1
Show all details

Spot 21 standard, wide distribution, ON/OFF, Ø105, traffic white (RAL 9016)

Order No.: 51SE147BB4BGTIN (EAN): 4058352631898

Colour temperature3000K
Colour renderingCRI > 90
Beam anglewide distribution
Luminous flux3900lm
Connected load
Luminous efficacy
ControlON/OFF
Dimension (mm)Ø105
Colourtraffic white (RAL 9016)
Wt. (kg)0.8
Show all details

Spot 21 standard, wide distribution, ON/OFF, Ø105, traffic white (RAL 9016)

Order No.: 51SE147BD4BGTIN (EAN): 4058352609705

Colour temperature4000K
Colour renderingCRI > 90
Beam anglewide distribution
Luminous flux3900lm
Connected load
Luminous efficacy
ControlON/OFF
Dimension (mm)Ø105
Colourtraffic white (RAL 9016)
Wt. (kg)0.8
Show all details

Spot 21 standard, wide distribution, ON/OFF, Ø105, traffic white (RAL 9016)

Order No.: 51SE147BA4BGTIN (EAN): 4058352609699

Colour temperature2700K
Colour renderingCRI > 90
Beam anglewide distribution
Luminous flux3900lm
Connected load
Luminous efficacy
ControlON/OFF
Dimension (mm)Ø105
Colourtraffic white (RAL 9016)
Wt. (kg)0.8
Show all details
