Family
Rondel 21 Performance. Our classic with unique modularity and lighting technology with an individual design language
Rondel 31 Standard. Proven technology for standard applications with good efficiency (121lm/W) and service life (50,000 hours)
Rondel 41 Basic. Practical, efficient and durable
SITECO Connect wireless by Casambi Components for the complete lighting solution. Energy-efficient. Scalable. EPBD-ready.
Product selection
Rondel 31
Key data
Article wall and ceiling luminaire
Lighting effect direct symmetric distribution, 120°
Net luminous flux 2500lm to 4700lm
Colour temperature 3000/4000K
Control ON/OFF Multilumen; DALI 2, Multilumen
Cover PMMA
Protection rating IP40
Insulation class insulation class I (protective earthing)
Impact resistance IK02
Special features
Luminaire in a minimalist design in three construction sizes for wall or ceiling surface mounting
For entrance areas, staircases, corridors, hallways and adjoining rooms
ON/OFF and DALI-2 versions for easy lighting control
Eight different lighting packages easily adjustable via DIP switch
Light colour between 3000 and 4000K easily adjustable via DIP switch
Easy installation, cover can be opened without tools via bayonet catch
The sensor and emergency lighting elements cannot be combined within a single luminaire
Configuration & data sheets
- ceiling or wall installation without other luminaire-specific mounting accessories
Results
Delivery time on request
Rondel 31, direct distribution, 120°, ON/OFF Multilumen, white
Order No.: 5PJDN11MA1G20B GTIN (EAN): 4069025155900
| Colour temperature | Colour rendering | Luminous flux | Pnom | Factory-preset luminous flux | Factory-preset Pnom | UGR | Control | D (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|
| 3000/4000K | CRI > 80 | 1100…2500lm | 9…20W | 2500lm | 20W | ON/OFF Multilumen | 290 | 0.8 | 108.50 |
Delivery time on request
Rondel 31, direct distribution, 120°, ON/OFF Multilumen, white
Order No.: 5PJDN11MB1G30B GTIN (EAN): 4069025155924
| Colour temperature | Colour rendering | Luminous flux | Pnom | Factory-preset luminous flux | Factory-preset Pnom | UGR | Control | D (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|
| 3000/4000K | CRI > 80 | 1600…3000lm | 12…24W | 3000lm | 24W | ON/OFF Multilumen | 360 | 1.3 | 129.70 |
Delivery time on request
Rondel 31, direct distribution, 120°, ON/OFF Multilumen, white
Order No.: 5PJDN11MC1G40B GTIN (EAN): 4069025155955
| Colour temperature | Colour rendering | Luminous flux | Pnom | Factory-preset luminous flux | Factory-preset Pnom | UGR | Control | D (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|
| 3000/4000K | CRI > 80 | 3200…4700lm | 25…39W | 4700lm | 39W | ON/OFF Multilumen | 464 | 1.7 | 176.60 |
Delivery time on request
Rondel 31, direct distribution, 120°, DALI 2, Multilumen, white
Order No.: 5PJDN11EA1G20B GTIN (EAN): 4069025155849
| Colour temperature | Colour rendering | Luminous flux | Pnom | Factory-preset luminous flux | Factory-preset Pnom | UGR | Control | D (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|
| 3000/4000K | CRI > 80 | 1100…2500lm | 9…20W | 2500lm | 20W | DALI 2, Multilumen | 290 | 0.8 | 151.00 |
Delivery time on request
Rondel 31, direct distribution, 120°, DALI 2, Multilumen, white
Order No.: 5PJDN11EB1G30B GTIN (EAN): 4069025155863
| Colour temperature | Colour rendering | Luminous flux | Pnom | Factory-preset luminous flux | Factory-preset Pnom | UGR | Control | D (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|
| 3000/4000K | CRI > 80 | 1600…3000lm | 12…24W | 3000lm | 24W | DALI 2, Multilumen | 360 | 1.0 | 181.00 |
Delivery time on request
Rondel 31, direct distribution, 120°, DALI 2, Multilumen, white
Order No.: 5PJDN11EC1G40B GTIN (EAN): 4069025155887
| Colour temperature | Colour rendering | Luminous flux | Pnom | Factory-preset luminous flux | Factory-preset Pnom | UGR | Control | D (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|
| 3000/4000K | CRI > 80 | 3200…4700lm | 25…39W | 4700lm | 39W | DALI 2, Multilumen | 464 | 1.7 | 234.20 |
Delivery time on request
Rondel 31, direct distribution, 120°, ON/OFF Multilumen, white
Order No.: 5PJDN11MA1G20BGTIN (EAN): 4069025155900
| Colour temperature | 3000/4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Luminous flux | 1100…2500lm |
| Pnom | 9…20W |
| Factory-preset luminous flux | 2500lm |
| Factory-preset Pnom | 20W |
| UGR | |
| Control | ON/OFF Multilumen |
| D (mm) | 290 |
| Wt. (kg) | 0.8 |
| Price (EUR) | 108.50 |
Delivery time on request
Rondel 31, direct distribution, 120°, ON/OFF Multilumen, white
Order No.: 5PJDN11MB1G30BGTIN (EAN): 4069025155924
| Colour temperature | 3000/4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Luminous flux | 1600…3000lm |
| Pnom | 12…24W |
| Factory-preset luminous flux | 3000lm |
| Factory-preset Pnom | 24W |
| UGR | |
| Control | ON/OFF Multilumen |
| D (mm) | 360 |
| Wt. (kg) | 1.3 |
| Price (EUR) | 129.70 |
Delivery time on request
Rondel 31, direct distribution, 120°, ON/OFF Multilumen, white
Order No.: 5PJDN11MC1G40BGTIN (EAN): 4069025155955
| Colour temperature | 3000/4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Luminous flux | 3200…4700lm |
| Pnom | 25…39W |
| Factory-preset luminous flux | 4700lm |
| Factory-preset Pnom | 39W |
| UGR | |
| Control | ON/OFF Multilumen |
| D (mm) | 464 |
| Wt. (kg) | 1.7 |
| Price (EUR) | 176.60 |
Delivery time on request
Rondel 31, direct distribution, 120°, DALI 2, Multilumen, white
Order No.: 5PJDN11EA1G20BGTIN (EAN): 4069025155849
| Colour temperature | 3000/4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Luminous flux | 1100…2500lm |
| Pnom | 9…20W |
| Factory-preset luminous flux | 2500lm |
| Factory-preset Pnom | 20W |
| UGR | |
| Control | DALI 2, Multilumen |
| D (mm) | 290 |
| Wt. (kg) | 0.8 |
| Price (EUR) | 151.00 |
Delivery time on request
Rondel 31, direct distribution, 120°, DALI 2, Multilumen, white
Order No.: 5PJDN11EB1G30BGTIN (EAN): 4069025155863
| Colour temperature | 3000/4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Luminous flux | 1600…3000lm |
| Pnom | 12…24W |
| Factory-preset luminous flux | 3000lm |
| Factory-preset Pnom | 24W |
| UGR | |
| Control | DALI 2, Multilumen |
| D (mm) | 360 |
| Wt. (kg) | 1.0 |
| Price (EUR) | 181.00 |
Delivery time on request
Rondel 31, direct distribution, 120°, DALI 2, Multilumen, white
Order No.: 5PJDN11EC1G40BGTIN (EAN): 4069025155887
| Colour temperature | 3000/4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Luminous flux | 3200…4700lm |
| Pnom | 25…39W |
| Factory-preset luminous flux | 4700lm |
| Factory-preset Pnom | 39W |
| UGR | |
| Control | DALI 2, Multilumen |
| D (mm) | 464 |
| Wt. (kg) | 1.7 |
| Price (EUR) | 234.20 |
