Licross
Product selection
Licross 21 Recessed luminaire insert IP40
Special features
A simple path to demand-oriented illumination due to several different light distributions
Uniform design due to rail-flush integration – and easy to install thanks to click system
Extremely efficient operation for low energy consumption and operating costs, high luminous flux up to 22710lm for high mounting heights
Links
Configuration & data sheets
- please order Licross trunking rails and trunking rail accessories separately
- versions with colour temperature 3000K, 5000K or 6500K on request
- with ceiling surface mounting: reducing of maximum allowable ambient temperature of 5°C
Results
Licross 21 Recessed HO, with lever catch, symmetric narrow distribution, IP40, AC
Order No.: 52TL11DV4LXR GTIN (EAN): 4058352470565
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 20370 | 122W | 167lm/W | DALI 2 | -35..+30°C | IP40 | 2250 | 2.3 |
Licross 21 Recessed MO, with lever catch, symmetric narrow distribution, IP40, AC
Order No.: 52TL11DV4EXF GTIN (EAN): 4058352470541
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 14070 | 87W | 161lm/W | DALI 2 | -25..+35°C | IP40 | 2250 | 2.0 |
Licross 21 Recessed HO, with lever catch, symmetric narrow distribution, IP40, AC
Order No.: 52TL11DV4LXRGTIN (EAN): 4058352470565
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 20370 |
| Connected load | 122W |
| Luminous efficacy | 167lm/W |
| Control | DALI 2 |
| ta | -35..+30°C |
| Protection rating | IP40 |
| L (mm) | 2250 |
| Wt. (kg) | 2.3 |
Licross 21 Recessed MO, with lever catch, symmetric narrow distribution, IP40, AC
Order No.: 52TL11DV4EXFGTIN (EAN): 4058352470541
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 14070 |
| Connected load | 87W |
| Luminous efficacy | 161lm/W |
| Control | DALI 2 |
| ta | -25..+35°C |
| Protection rating | IP40 |
| L (mm) | 2250 |
| Wt. (kg) | 2.0 |
