Floodlight FL 11
With the Floodlight FL 11 from SITECO you don't have to make any compromises. Regardless of whether it is a soccer field, sports arena, airport or logistics area, this floodlight offers completely new possibilities for illuminating areas down to the last detail and always reacting flexibly to all eventualities. With our power solution you save money, electricity and CO2. It manages with fewer floodlights than a comparable LED solution, but illuminates surfaces even more precisely thanks to new light distributions. Stay flexible in planning, installation, alignment and control. This also includes the flexible placement of the ECG, 360° rotatable LED modules and two construction sizes.
Our performance solution: Floodlight FL 11 is our innovative floodlight with maximum efficiency, service life and flexibility
Floodlight FL 11 maxi pro Remote for remote ECG mounting
Intro to Productfamily
Data
Varetekst flomlys
Lyseffekt direkte asymmetrisk strålende; direkte rotasjonssymmetrisk strålende
Lysfordeling PL43; PL52; RS07; RS08; RS12; PL64; RSD11; RSD12; RSD13
Netto lysfluks 107210lm til 173640lm
Fargetemperatur 4000K; 5000K; 5700K
Styring DMX+RDM
Specials
Configuration & Datasheets
- Netto lysfluksangivelse er basert på en årlig gjennomsnittlig omgivelsestemperatur på 10°C
Results
Floodlight FL 11 maxi pro Remote, flomlys, PL43, asymmetrisk strålende, Anti Glow
Fargetemperatur | Fargegjengivelse | Lysfluks | Tilkoblingseffekt | Pred (W) ved 50 % lysfluks | Lysutbytte | Styring | Vekt (kg) |
---|---|---|---|---|---|---|---|
5700K | CRI > 90 | 130000lm | 1335W | 534 | 97lm/W | DMX+RDM | 29,6 |
Floodlight FL 11 maxi pro Remote, flomlys, PL64, asymmetrisk strålende, Anti Glow
Fargetemperatur | Fargegjengivelse | Lysfluks | Tilkoblingseffekt | Pred (W) ved 50 % lysfluks | Lysutbytte | Styring | Vekt (kg) |
---|---|---|---|---|---|---|---|
5700K | CRI > 90 | 128450lm | 1335W | 534 | 96lm/W | DMX+RDM | 29,6 |
Floodlight FL 11 maxi pro Remote, flomlys, RS07, rotasjonssymmetrisk strålende, Anti Glow
Fargetemperatur | Fargegjengivelse | Lysfluks | Tilkoblingseffekt | Pred (W) ved 50 % lysfluks | Lysutbytte | Styring | Vekt (kg) |
---|---|---|---|---|---|---|---|
5700K | CRI > 90 | 129300lm | 1335W | 534 | 97lm/W | DMX+RDM | 29,6 |
Floodlight FL 11 maxi pro Remote, flomlys, RS08, rotasjonssymmetrisk strålende, Anti Glow
Fargetemperatur | Fargegjengivelse | Lysfluks | Tilkoblingseffekt | Pred (W) ved 50 % lysfluks | Lysutbytte | Styring | Vekt (kg) |
---|---|---|---|---|---|---|---|
5700K | CRI > 90 | 127930lm | 1335W | 534 | 96lm/W | DMX+RDM | 29,6 |
Floodlight FL 11 maxi pro Remote, flomlys, RS12, rotasjonssymmetrisk strålende, Anti Glow
Fargetemperatur | Fargegjengivelse | Lysfluks | Tilkoblingseffekt | Pred (W) ved 50 % lysfluks | Lysutbytte | Styring | Vekt (kg) |
---|---|---|---|---|---|---|---|
5700K | CRI > 90 | 131650lm | 1335W | 534 | 99lm/W | DMX+RDM | 29,6 |
Floodlight FL 11 maxi pro Remote, flomlys, RSD12, rotasjonssymmetrisk strålende, Anti Glow
Fargetemperatur | Fargegjengivelse | Lysfluks | Tilkoblingseffekt | Pred (W) ved 50 % lysfluks | Lysutbytte | Styring | Vekt (kg) |
---|---|---|---|---|---|---|---|
5700K | CRI > 90 | 169510lm | 1481W | 114lm/W | DMX+RDM | 29,6 |
Floodlight FL 11 maxi pro Remote, flomlys, RSD11, rotasjonssymmetrisk strålende, Anti Glow
Fargetemperatur | Fargegjengivelse | Lysfluks | Tilkoblingseffekt | Pred (W) ved 50 % lysfluks | Lysutbytte | Styring | Vekt (kg) |
---|---|---|---|---|---|---|---|
5700K | CRI > 90 | 163830lm | 1481W | 111lm/W | DMX+RDM | 29,6 |
Floodlight FL 11 maxi pro Remote, flomlys, RSD13, rotasjonssymmetrisk strålende, Anti Glow
Fargetemperatur | Fargegjengivelse | Lysfluks | Tilkoblingseffekt | Pred (W) ved 50 % lysfluks | Lysutbytte | Styring | Vekt (kg) |
---|---|---|---|---|---|---|---|
5700K | CRI > 90 | 168520lm | 1481W | 114lm/W | DMX+RDM | 29,6 |
Floodlight FL 11 maxi pro Remote, flomlys, PL43, asymmetrisk strålende, Anti Glow
Fargetemperatur | Fargegjengivelse | Lysfluks | Tilkoblingseffekt | Pred (W) ved 50 % lysfluks | Lysutbytte | Styring | Vekt (kg) |
---|---|---|---|---|---|---|---|
5700K | CRI > 90 | 108940lm | 1021W | 440 | 107lm/W | DMX+RDM | 30,0 |
Floodlight FL 11 maxi pro Remote, flomlys, PL64, asymmetrisk strålende, Anti Glow
Fargetemperatur | Fargegjengivelse | Lysfluks | Tilkoblingseffekt | Pred (W) ved 50 % lysfluks | Lysutbytte | Styring | Vekt (kg) |
---|---|---|---|---|---|---|---|
5700K | CRI > 90 | 107650lm | 1021W | 440 | 105lm/W | DMX+RDM | 30,0 |
Floodlight FL 11 maxi pro Remote, flomlys, RS07, rotasjonssymmetrisk strålende, Anti Glow
Fargetemperatur | Fargegjengivelse | Lysfluks | Tilkoblingseffekt | Pred (W) ved 50 % lysfluks | Lysutbytte | Styring | Vekt (kg) |
---|---|---|---|---|---|---|---|
5700K | CRI > 90 | 108360lm | 1021W | 440 | 106lm/W | DMX+RDM | 30,0 |
Floodlight FL 11 maxi pro Remote, flomlys, RS08, rotasjonssymmetrisk strålende, Anti Glow
Fargetemperatur | Fargegjengivelse | Lysfluks | Tilkoblingseffekt | Pred (W) ved 50 % lysfluks | Lysutbytte | Styring | Vekt (kg) |
---|---|---|---|---|---|---|---|
5700K | CRI > 90 | 107210lm | 1021W | 440 | 105lm/W | DMX+RDM | 30,0 |
Floodlight FL 11 maxi pro Remote, flomlys, RS12, rotasjonssymmetrisk strålende, Anti Glow
Fargetemperatur | Fargegjengivelse | Lysfluks | Tilkoblingseffekt | Pred (W) ved 50 % lysfluks | Lysutbytte | Styring | Vekt (kg) |
---|---|---|---|---|---|---|---|
5700K | CRI > 90 | 110330lm | 1021W | 440 | 108lm/W | DMX+RDM | 30,0 |
Floodlight FL 11 maxi pro Remote, flomlys, RSD12, rotasjonssymmetrisk strålende, Anti Glow
Fargetemperatur | Fargegjengivelse | Lysfluks | Tilkoblingseffekt | Pred (W) ved 50 % lysfluks | Lysutbytte | Styring | Vekt (kg) |
---|---|---|---|---|---|---|---|
5700K | CRI > 90 | 128560lm | 1051W | 122lm/W | DMX+RDM | 30,0 |
Floodlight FL 11 maxi pro Remote, flomlys, RSD11, rotasjonssymmetrisk strålende, Anti Glow
Fargetemperatur | Fargegjengivelse | Lysfluks | Tilkoblingseffekt | Pred (W) ved 50 % lysfluks | Lysutbytte | Styring | Vekt (kg) |
---|---|---|---|---|---|---|---|
5700K | CRI > 90 | 124250lm | 1051W | 118lm/W | DMX+RDM | 30,0 |
Floodlight FL 11 maxi pro Remote, flomlys, RSD13, rotasjonssymmetrisk strålende, Anti Glow
Fargetemperatur | Fargegjengivelse | Lysfluks | Tilkoblingseffekt | Pred (W) ved 50 % lysfluks | Lysutbytte | Styring | Vekt (kg) |
---|---|---|---|---|---|---|---|
5700K | CRI > 90 | 127800lm | 1051W | 122lm/W | DMX+RDM | 30,0 |
Floodlight FL 11 maxi pro Remote, flomlys, PL52, asymmetrisk strålende, Anti Glow
Fargetemperatur | Fargegjengivelse | Lysfluks | Tilkoblingseffekt | Pred (W) ved 50 % lysfluks | Lysutbytte | Styring | Vekt (kg) |
---|---|---|---|---|---|---|---|
5000K | CRI > 70 | 173640lm | 1426W | 122lm/W | DALI 2 (1 DALI-adresse) | 29,6 |
Floodlight FL 11 maxi pro Remote, flomlys, PL52, asymmetrisk strålende, Anti Glow
Fargetemperatur | Fargegjengivelse | Lysfluks | Tilkoblingseffekt | Pred (W) ved 50 % lysfluks | Lysutbytte | Styring | Vekt (kg) |
---|---|---|---|---|---|---|---|
5000K | CRI > 70 | 148120lm | 1096W | 135lm/W | DALI 2 (1 DALI-adresse) | 29,6 |
Floodlight FL 11 maxi pro Remote, flomlys, PL52, asymmetrisk strålende, Anti Glow
Fargetemperatur | Fargegjengivelse | Lysfluks | Tilkoblingseffekt | Pred (W) ved 50 % lysfluks | Lysutbytte | Styring | Vekt (kg) |
---|---|---|---|---|---|---|---|
4000K | CRI > 70 | 169140lm | 1388W | 122lm/W | DALI 2 (1 DALI-adresse) | 29,6 |
Floodlight FL 11 maxi pro Remote, flomlys, PL52, asymmetrisk strålende, Anti Glow
Fargetemperatur | Fargegjengivelse | Lysfluks | Tilkoblingseffekt | Pred (W) ved 50 % lysfluks | Lysutbytte | Styring | Vekt (kg) |
---|---|---|---|---|---|---|---|
4000K | CRI > 70 | 146220lm | 1096W | 133lm/W | DALI 2 (1 DALI-adresse) | 29,6 |
Floodlight FL 11 maxi pro Remote, flomlys, PL43, asymmetrisk strålende, Anti Glow
Bestillingsnummer: 5XA779524A01AAGTIN (EAN): 4058352574201
Fargetemperatur | 5700K |
---|---|
Fargegjengivelse | CRI > 90 |
Lysfluks | 130000lm |
Tilkoblingseffekt | 1335W |
Pred (W) ved 50 % lysfluks | 534 |
Lysutbytte | 97lm/W |
Styring | DMX+RDM |
Vekt (kg) | 29,6 |
Floodlight FL 11 maxi pro Remote, flomlys, PL64, asymmetrisk strålende, Anti Glow
Bestillingsnummer: 5XA779524E01AAGTIN (EAN): 4058352574232
Fargetemperatur | 5700K |
---|---|
Fargegjengivelse | CRI > 90 |
Lysfluks | 128450lm |
Tilkoblingseffekt | 1335W |
Pred (W) ved 50 % lysfluks | 534 |
Lysutbytte | 96lm/W |
Styring | DMX+RDM |
Vekt (kg) | 29,6 |
Floodlight FL 11 maxi pro Remote, flomlys, RS07, rotasjonssymmetrisk strålende, Anti Glow
Bestillingsnummer: 5XA779524K01AAGTIN (EAN): 4058352574270
Fargetemperatur | 5700K |
---|---|
Fargegjengivelse | CRI > 90 |
Lysfluks | 129300lm |
Tilkoblingseffekt | 1335W |
Pred (W) ved 50 % lysfluks | 534 |
Lysutbytte | 97lm/W |
Styring | DMX+RDM |
Vekt (kg) | 29,6 |
Floodlight FL 11 maxi pro Remote, flomlys, RS08, rotasjonssymmetrisk strålende, Anti Glow
Bestillingsnummer: 5XA779524L01AAGTIN (EAN): 4058352574317
Fargetemperatur | 5700K |
---|---|
Fargegjengivelse | CRI > 90 |
Lysfluks | 127930lm |
Tilkoblingseffekt | 1335W |
Pred (W) ved 50 % lysfluks | 534 |
Lysutbytte | 96lm/W |
Styring | DMX+RDM |
Vekt (kg) | 29,6 |
Floodlight FL 11 maxi pro Remote, flomlys, RS12, rotasjonssymmetrisk strålende, Anti Glow
Bestillingsnummer: 5XA779524M01AAGTIN (EAN): 4058352574362
Fargetemperatur | 5700K |
---|---|
Fargegjengivelse | CRI > 90 |
Lysfluks | 131650lm |
Tilkoblingseffekt | 1335W |
Pred (W) ved 50 % lysfluks | 534 |
Lysutbytte | 99lm/W |
Styring | DMX+RDM |
Vekt (kg) | 29,6 |
Floodlight FL 11 maxi pro Remote, flomlys, RSD12, rotasjonssymmetrisk strålende, Anti Glow
Bestillingsnummer: 5XA779524N01AAGTIN (EAN): 4058352574393
Fargetemperatur | 5700K |
---|---|
Fargegjengivelse | CRI > 90 |
Lysfluks | 169510lm |
Tilkoblingseffekt | 1481W |
Pred (W) ved 50 % lysfluks | |
Lysutbytte | 114lm/W |
Styring | DMX+RDM |
Vekt (kg) | 29,6 |
Floodlight FL 11 maxi pro Remote, flomlys, RSD11, rotasjonssymmetrisk strålende, Anti Glow
Bestillingsnummer: 5XA779524O01AAGTIN (EAN): 4058352574430
Fargetemperatur | 5700K |
---|---|
Fargegjengivelse | CRI > 90 |
Lysfluks | 163830lm |
Tilkoblingseffekt | 1481W |
Pred (W) ved 50 % lysfluks | |
Lysutbytte | 111lm/W |
Styring | DMX+RDM |
Vekt (kg) | 29,6 |
Floodlight FL 11 maxi pro Remote, flomlys, RSD13, rotasjonssymmetrisk strålende, Anti Glow
Bestillingsnummer: 5XA779524P01AAGTIN (EAN): 4058352574478
Fargetemperatur | 5700K |
---|---|
Fargegjengivelse | CRI > 90 |
Lysfluks | 168520lm |
Tilkoblingseffekt | 1481W |
Pred (W) ved 50 % lysfluks | |
Lysutbytte | 114lm/W |
Styring | DMX+RDM |
Vekt (kg) | 29,6 |
Floodlight FL 11 maxi pro Remote, flomlys, PL43, asymmetrisk strålende, Anti Glow
Bestillingsnummer: 5XA779524A01BAGTIN (EAN): 4058352574218
Fargetemperatur | 5700K |
---|---|
Fargegjengivelse | CRI > 90 |
Lysfluks | 108940lm |
Tilkoblingseffekt | 1021W |
Pred (W) ved 50 % lysfluks | 440 |
Lysutbytte | 107lm/W |
Styring | DMX+RDM |
Vekt (kg) | 30,0 |
Floodlight FL 11 maxi pro Remote, flomlys, PL64, asymmetrisk strålende, Anti Glow
Bestillingsnummer: 5XA779524E01BAGTIN (EAN): 4058352574256
Fargetemperatur | 5700K |
---|---|
Fargegjengivelse | CRI > 90 |
Lysfluks | 107650lm |
Tilkoblingseffekt | 1021W |
Pred (W) ved 50 % lysfluks | 440 |
Lysutbytte | 105lm/W |
Styring | DMX+RDM |
Vekt (kg) | 30,0 |
Floodlight FL 11 maxi pro Remote, flomlys, RS07, rotasjonssymmetrisk strålende, Anti Glow
Bestillingsnummer: 5XA779524K01BAGTIN (EAN): 4058352574294
Fargetemperatur | 5700K |
---|---|
Fargegjengivelse | CRI > 90 |
Lysfluks | 108360lm |
Tilkoblingseffekt | 1021W |
Pred (W) ved 50 % lysfluks | 440 |
Lysutbytte | 106lm/W |
Styring | DMX+RDM |
Vekt (kg) | 30,0 |
Floodlight FL 11 maxi pro Remote, flomlys, RS08, rotasjonssymmetrisk strålende, Anti Glow
Bestillingsnummer: 5XA779524L01BAGTIN (EAN): 4058352574331
Fargetemperatur | 5700K |
---|---|
Fargegjengivelse | CRI > 90 |
Lysfluks | 107210lm |
Tilkoblingseffekt | 1021W |
Pred (W) ved 50 % lysfluks | 440 |
Lysutbytte | 105lm/W |
Styring | DMX+RDM |
Vekt (kg) | 30,0 |
Floodlight FL 11 maxi pro Remote, flomlys, RS12, rotasjonssymmetrisk strålende, Anti Glow
Bestillingsnummer: 5XA779524M01BAGTIN (EAN): 4058352574379
Fargetemperatur | 5700K |
---|---|
Fargegjengivelse | CRI > 90 |
Lysfluks | 110330lm |
Tilkoblingseffekt | 1021W |
Pred (W) ved 50 % lysfluks | 440 |
Lysutbytte | 108lm/W |
Styring | DMX+RDM |
Vekt (kg) | 30,0 |
Floodlight FL 11 maxi pro Remote, flomlys, RSD12, rotasjonssymmetrisk strålende, Anti Glow
Bestillingsnummer: 5XA779524N01BAGTIN (EAN): 4058352574416
Fargetemperatur | 5700K |
---|---|
Fargegjengivelse | CRI > 90 |
Lysfluks | 128560lm |
Tilkoblingseffekt | 1051W |
Pred (W) ved 50 % lysfluks | |
Lysutbytte | 122lm/W |
Styring | DMX+RDM |
Vekt (kg) | 30,0 |
Floodlight FL 11 maxi pro Remote, flomlys, RSD11, rotasjonssymmetrisk strålende, Anti Glow
Bestillingsnummer: 5XA779524O01BAGTIN (EAN): 4058352574454
Fargetemperatur | 5700K |
---|---|
Fargegjengivelse | CRI > 90 |
Lysfluks | 124250lm |
Tilkoblingseffekt | 1051W |
Pred (W) ved 50 % lysfluks | |
Lysutbytte | 118lm/W |
Styring | DMX+RDM |
Vekt (kg) | 30,0 |
Floodlight FL 11 maxi pro Remote, flomlys, RSD13, rotasjonssymmetrisk strålende, Anti Glow
Bestillingsnummer: 5XA779524P01BAGTIN (EAN): 4058352574492
Fargetemperatur | 5700K |
---|---|
Fargegjengivelse | CRI > 90 |
Lysfluks | 127800lm |
Tilkoblingseffekt | 1051W |
Pred (W) ved 50 % lysfluks | |
Lysutbytte | 122lm/W |
Styring | DMX+RDM |
Vekt (kg) | 30,0 |
Floodlight FL 11 maxi pro Remote, flomlys, PL52, asymmetrisk strålende, Anti Glow
Bestillingsnummer: 5XA779427D01AAGTIN (EAN): 4058352597323
Fargetemperatur | 5000K |
---|---|
Fargegjengivelse | CRI > 70 |
Lysfluks | 173640lm |
Tilkoblingseffekt | 1426W |
Pred (W) ved 50 % lysfluks | |
Lysutbytte | 122lm/W |
Styring | DALI 2 (1 DALI-adresse) |
Vekt (kg) | 29,6 |
Floodlight FL 11 maxi pro Remote, flomlys, PL52, asymmetrisk strålende, Anti Glow
Bestillingsnummer: 5XA779427D01BAGTIN (EAN): 4058352608166
Fargetemperatur | 5000K |
---|---|
Fargegjengivelse | CRI > 70 |
Lysfluks | 148120lm |
Tilkoblingseffekt | 1096W |
Pred (W) ved 50 % lysfluks | |
Lysutbytte | 135lm/W |
Styring | DALI 2 (1 DALI-adresse) |
Vekt (kg) | 29,6 |
Floodlight FL 11 maxi pro Remote, flomlys, PL52, asymmetrisk strålende, Anti Glow
Bestillingsnummer: 5XA779426D01AAGTIN (EAN): 4058352608135
Fargetemperatur | 4000K |
---|---|
Fargegjengivelse | CRI > 70 |
Lysfluks | 169140lm |
Tilkoblingseffekt | 1388W |
Pred (W) ved 50 % lysfluks | |
Lysutbytte | 122lm/W |
Styring | DALI 2 (1 DALI-adresse) |
Vekt (kg) | 29,6 |
Floodlight FL 11 maxi pro Remote, flomlys, PL52, asymmetrisk strålende, Anti Glow
Bestillingsnummer: 5XA779426D01BAGTIN (EAN): 4058352608142
Fargetemperatur | 4000K |
---|---|
Fargegjengivelse | CRI > 70 |
Lysfluks | 146220lm |
Tilkoblingseffekt | 1096W |
Pred (W) ved 50 % lysfluks | |
Lysutbytte | 133lm/W |
Styring | DALI 2 (1 DALI-adresse) |
Vekt (kg) | 29,6 |
Optional accessory
Bestillingsnummer: 5NY76901XA31GTIN (EAN): 4058352144510 | Show details |
Bestillingsnummer: 5NY74901XA31GTIN (EAN): 4039806383440 | Show details |
Bestillingsnummer: 5NY76902XA31GTIN (EAN): 4058352144527 | Show details |
Bestillingsnummer: 5NY76903XA31GTIN (EAN): 4058352493694 | Show details |
