5EA3CLS02

Order No.: 5EA3CLS02
Remember articleRemember article

Article luminaire controller
Product name SITECO Connect Wireless
Protection rating IP66
Weight 0.1kg

SITECO Connect WirelessSmart Plug LoRaWAN, luminaire controller, radio, communication: LoRaWAN, D4i type A, control: remote setup and operation, sensor technology: daylight sensor, Smart Interface below and above, The LoRaWAN keys are transmitted as a file, installation type: screw fastening, installation location: to the luminaire, Smart Interface above: Zhaga, Smart Interface below: Zhaga, of PBT, voltage: 24V, voltage type: DC, protection rating (complete): IP66, certification: CE, packaging unit: set of 48

Downloads

Technical product information
Data for applications

Product details

Key data

System family SITECO Connect
Product type luminaire controller
Product name SITECO Connect Wireless
Order No. 5EA3CLS02

Control

Certificates, Standards

Protection rating IP66
Temperature range (operation) -40..+70°C
Standard according to Zhaga book 18
Certification, designation CE

Material, Colour

housing PBT, transparent, colour-backed, transparent

Mounting

Mounting method, mounting location screw fastening, to the luminaire

Electrical connection

Nominal voltage 24V, DC

Dimensions, Weight

Diameter 80mm
Height 45mm
Weight 0.1kg

System family
SITECO Connect

Product type
luminaire controller

Product name
SITECO Connect Wireless

Order No.
5EA3CLS02

Protection rating
IP66

Temperature range (operation)
-40..+70°C

Standard
according to Zhaga book 18

Certification, designation
CE

housing
PBT, transparent, colour-backed, transparent

Mounting method, mounting location
screw fastening, to the luminaire

Nominal voltage
24V, DC

Diameter
80mm

Height
45mm

Weight
0.1kg
