Floodlight FL 20 mini

housing frame

: 5XA7671C0000C

Article housing
Product name Floodlight FL 20 mini
Rated input power 96W
Protection rating IP66
Weight 3.3kg

Floodlight FL 20 mini, housing, primary light characteristic: asymmetric, control gear: Basic, control: overheat protection, power reduction, electronic power reduction, with terminal, 5-pole, max. 2.5mm², mains connection: 220..240V, AC, rated input power: 96W, housing frame, housing, of diecast aluminium, powder-coated, SITECO metallic grey (DB 702S), incl. 1x M20 cable gland for cable Ø 6.5..12mm, solid metal housing for good heat sinkage, length: 446mm, width: 355mm, height: 62mm, ON/OFF, protection rating (complete): IP66, insulation class (complete): insulation class I (protective earthing), certification: CE, standard: DIN EN 12944, packaging unit: 1 piece

Downloads

Key data

Product type housing
Product name Floodlight FL 20 mini
Order No. 5XA7671C0000C

Lighting technology

Symmetry asymmetric distribution

Lamps

Rated input power 96W

Operating device

Control gear ECG Basic
Control Basic
Equipment overheat protection, power reduction
Switching method electronic power reduction

Certificates, Standards

Protection rating IP66
Insulation class insulation class I (protective earthing)
Standard DIN EN 12944
Certification, designation CE

Material, Colour

housing frame diecast aluminium, powder-coated, SITECO metallic grey (DB 702S), incl. 1x M20 cable gland for cable Ø 6.5..12mm
housing diecast aluminium, powder-coated, SITECO metallic grey (DB 702S), incl. 1x M20 cable gland for cable Ø 6.5..12mm

Electrical connection

Connection terminal, 5-pole, max. 2.5mm²
Nominal voltage 220..240V, AC

Dimensions, Weight

Length 446mm
Width 355mm
Height 62mm
Weight 3.3kg

Product type
housing

Product name
Floodlight FL 20 mini

Order No.
5XA7671C0000C

Symmetry
asymmetric distribution

Rated input power
96W

Control gear
ECG Basic

Control
Basic

Equipment
overheat protection, power reduction

Switching method
electronic power reduction

Protection rating
IP66

Insulation class
insulation class I (protective earthing)

Standard
DIN EN 12944

Certification, designation
CE

housing frame
diecast aluminium, powder-coated, SITECO metallic grey (DB 702S), incl. 1x M20 cable gland for cable Ø 6.5..12mm

housing
diecast aluminium, powder-coated, SITECO metallic grey (DB 702S), incl. 1x M20 cable gland for cable Ø 6.5..12mm

Connection
terminal, 5-pole, max. 2.5mm²

Nominal voltage
220..240V, AC

Length
446mm

Width
355mm

Height
62mm

Weight
3.3kg
