56TL1FAMA

: 56TL1FAMA

Article base module
Product name Licross Interface
Protection rating IP20
Weight 0.5kg

Licross InterfaceInterface MS, master, local control - self-sufficient standalone sensors, switchable, installation location: to the Licross trunking rail, of sheet steel, protection rating (complete): IP20, insulation class (complete): insulation class I (protective earthing), certification: CE, ENEC, VDE, UKCA, voltage: 230V, voltage type: AC, packaging unit: 1 piece

Downloads

Key data

System family SITECO Connect 31 Logistic On/Off
Product type base module
Product name Licross Interface
Order No. 56TL1FAMA

Lamps

Supplement internal wiring halogen-free

Operating device

Control ON/OFF, switchable

Certificates, Standards

Protection rating IP20
Insulation class insulation class I (protective earthing)
Temperature range (operation) -20..+50°C
Certification, designation CE, ENEC, VDE, UKCA

Material, Colour

trunking rail adapter set sheet steel, coil coated, white

Mounting

Supplement only suitable for use in indoor areas

Electrical connection

Connection plug, 4-pole, without phase selection
Nominal voltage 230V, 50Hz, AC

Dimensions, Weight

Length 500mm
Width 96mm
Height 97mm
Weight 0.5kg

System family
SITECO Connect 31 Logistic On/Off

Product type
base module

Product name
Licross Interface

Order No.
56TL1FAMA

Supplement
internal wiring halogen-free

Control
ON/OFF, switchable

Protection rating
IP20

Insulation class
insulation class I (protective earthing)

Temperature range (operation)
-20..+50°C

Certification, designation
CE, ENEC, VDE, UKCA

trunking rail adapter set
sheet steel, coil coated, white

Supplement
only suitable for use in indoor areas

Connection
plug, 4-pole, without phase selection

Nominal voltage
230V, 50Hz, AC

Length
500mm

Width
96mm

Height
97mm

Weight
0.5kg
