: 5EA40TMC01

Article luminaire controller
Product name SITECO Connect Wireless
Protection rating IP66
Impact resistance IK08
Weight 0.1kg

SITECO Connect WirelessSmart Plug Motion 2PIR Casambi, luminaire controller, communication: 2.4GHz, local mesh radio network, Bluetooth, D4i type A, control: local setting and operation with smartphone app, manual, by daylight, optionally via radio push button, by movement, sensor technology: daylight sensor, 2 PIR movement sensors, configuration via Casambi app, Compatible only with ECGs with logarithmic DALI dimming curve, optional remote setup and operation via gateway, installation type: screw fastening, installation location: to the luminaire, Smart Interface below: Zhaga, of plastic, voltage: 12..20V, voltage type: DC, PIR movement sensor, protection rating (complete): IP66, certification: CE, UKCA, packaging unit: 1 piece

Downloads


Key data

System family SITECO Connect 31 Wireless
Product type luminaire controller
Product name SITECO Connect Wireless
Order No. 5EA40TMC01


Control


Certificates, Standards

Protection rating IP66
Impact resistance IK08
Temperature range (operation) -20..+50°C
Standard according to Zhaga book 18
Certification, designation CE, UKCA


Material, Colour

housing plastic, grey


Mounting

Mounting method, mounting location screw fastening, to the luminaire


Electrical connection

Nominal voltage 12..20V, DC


Dimensions, Weight

Weight 0.1kg


Inputs

PIR movement sensor
Detection range max. 35x16m

System family
SITECO Connect 31 Wireless

Product type
luminaire controller

Product name
SITECO Connect Wireless

Order No.
5EA40TMC01

Protection rating
IP66

Impact resistance
IK08

Temperature range (operation)
-20..+50°C

Standard
according to Zhaga book 18

Certification, designation
CE, UKCA

housing
plastic, grey

Mounting method, mounting location
screw fastening, to the luminaire

Nominal voltage
12..20V, DC

Weight
0.1kg

PIR movement sensor

Detection range
max. 35x16m
