5LZ980301A

Order No.: 5LZ980301A
Remember articleRemember article

Article control unit
Product name SITECO Connect Wireless
Protection rating IP20
Weight 0.1kg

SITECO Connect Wirelesscontroller, control unit, master, local control - self-sufficient standalone sensors, dimmable, installation type: recessed, installation location: in the ceiling, of plastic, voltage: 230V, 1 x push button input, 1 x DALI, 1 x Bluetooth interface, protection rating (complete): IP20, insulation class (complete): insulation class I (protective earthing), certification: CE, packaging unit: 1 piece

Downloads

Technical product information
Data for applications

Product details

Key data

System family SITECO Connect Wireless
Product type control unit
Product name SITECO Connect Wireless
Order No. 5LZ980301A

Control

Certificates, Standards

Protection rating IP20
Insulation class insulation class I (protective earthing)
Temperature range (operation) -20..+70°C
Certification, designation CE

Material, Colour

housing plastic, white
housing plastic, white

Mounting

Mounting method, mounting location recessed, in the ceiling
Supplement only suitable for use in indoor areas

Electrical connection

Nominal voltage 230V, 50/60Hz

Dimensions, Weight

Length 208mm
Width 79mm
Height 30mm
Weight 0.1kg

Outputs

1x DALI
System current max. 50mA
Feature DALI, master function, broadcast addressing, max. 25 DALI ECGs

1x Bluetooth interface
Feature wireless networking

System family
SITECO Connect Wireless

Product type
control unit

Product name
SITECO Connect Wireless

Order No.
5LZ980301A

Protection rating
IP20

Insulation class
insulation class I (protective earthing)

Temperature range (operation)
-20..+70°C

Certification, designation
CE

housing
plastic, white

housing
plastic, white

Mounting method, mounting location
recessed, in the ceiling

Supplement
only suitable for use in indoor areas

Nominal voltage
230V, 50/60Hz

Length
208mm

Width
79mm

Height
30mm

Weight
0.1kg

1x DALI

System current
max. 50mA

Feature
DALI, master function, broadcast addressing, max. 25 DALI ECGs

1x Bluetooth interface

Feature
wireless networking
