5XA1565E1V3
Article electrics components group
Product name Large Bell iQ
Lamp LED
Rated luminous flux 4750lm
Luminous efficacy 138.5lm/W
Colour temperature 3000K
Colour rendering CRI > 70
Pnom 34.3W
Pnom end service life 37.7W
Pred at 50% lumin. flux 15.5W
Weight 4.0kg
Large Bell iQ, electrics components group, gear tray with cover, primary light control with 3 zone facetted reflector, of plastic, silver coated, primary optical cover: cover panel, of toughened safety glass, transparent, light distribution: S120016, primary beam angle: wide distribution, primary light characteristic: asymmetric, lamps: LED, rated values: 4.750lm | 34,3W | 138,5lm/W (begin service life); end service life: 4.750lm | 37,7W; at 50% lumin. flux: 2.375lm | 15,5W | 153,2lm/W, colour temperature: 3000K, colour rendering: CRI > 70, light colour: 730, light setting 1 (further light settings possible): 100% | 4.750lm | 34,3W | 138,5lm/W | 3.000K (begin service life); end service life: 37,7W, control gear: iQ-Street Remote, D4i with power reductionD4iiQ Smart Interface, control: pre-setting: logarithmic dimming characteristic, Street-Remote, Auto-Match, Temp-Guard, Lumen-Switch, Night-Set, Smart-Wire, Light-Fading, Desk-Remote (wireless, voltage-free reading and setting of iQ features in the workshop via application-optimized NFC function/RFID function), optimised constant luminous flux control (CLO 2.0), mains connection: 220..240V, AC, 50/60Hz, surge voltage resistance: surge voltage resistance: 10kV (common mode); 6kV (differential mode), gear tray with cover, Smart Interface above: Zhaga, insulation class (complete): insulation class II (safety insulation), certification: CE, ENEC, VDE, packaging unit: 1 piece
