5XA769SCSDMX

: 5XA769SCSDMX

Article luminaire controller
Product name SITECO Connect Sport
Rated input power 3W
Protection rating IP66
Weight 0.2kg

SITECO Connect SportMast Box DMX 230V, local control - self-sufficient standalone sensors, dimmable, configuration via Casambi app, controls up to 4 DALI ECGs individually or up to 64 DALI ECGs via broadcast, optional remote setup and operation via gateway, installation type: surface-mounted, installation location: to mast, of plastic, protection rating (complete): IP66, insulation class (complete): insulation class II (safety insulation), certification: CE, voltage: 230V, voltage type: AC, DMX/RDM, Bluetooth, packaging unit: 1 piece

Downloads

Key data

Product type luminaire controller
Product name SITECO Connect Sport
Order No. 5XA769SCSDMX

Lamps

Rated input power 3W

Operating device

Control DMX, dimmable, configuration via Casambi app, controls up to 4 DALI ECGs individually or up to 64 DALI ECGs via broadcast, optional remote setup and operation via gateway
Equipment Bluetooth 4.0

Certificates, Standards

Protection rating IP66
Insulation class insulation class II (safety insulation)
Temperature range (operation) -25..+60°C
Certification, designation CE

Material, Colour

housing plastic, black

Mounting

Mounting method, mounting location surface-mounted, to mast

Electrical connection

Nominal voltage 230V, 50/60Hz, AC

Dimensions, Weight

Weight 0.2kg

Outputs

Bluetooth
Range max. 100m in open field

Product type
luminaire controller

Product name
SITECO Connect Sport

Order No.
5XA769SCSDMX

Rated input power
3W

Control
DMX, dimmable, configuration via Casambi app, controls up to 4 DALI ECGs individually or up to 64 DALI ECGs via broadcast, optional remote setup and operation via gateway

Equipment
Bluetooth 4.0

Protection rating
IP66

Insulation class
insulation class II (safety insulation)

Temperature range (operation)
-25..+60°C

Certification, designation
CE

housing
plastic, black

Mounting method, mounting location
surface-mounted, to mast

Nominal voltage
230V, 50/60Hz, AC

Weight
0.2kg

Bluetooth

Range
max. 100m in open field
