5TR91AFN0

: 5TR91AFN0

Article infeed
Product name Modario 31
Protection rating IP40
Weight 0.7kg

Modario 31 connection compartment, pure white; connection compartment of sheet steel, galvanised, coated, with cable entry for four cables, Ø 8.5..13mm; 2x end cap 1x blank cover of PC/ABS, white; 1x connector of steel, galvanised, connector pre-assembled on trunking rail; dimension: (LxWxH) = 299 x 58 x 43mm; IP40; insulation class: insulation class I (protective earthing); certification: CE, UKCA; packaging unit: 1 piece

Downloads

Key data

Product type infeed
Product name Modario 31
Order No. 5TR91AFN0

Certificates, Standards

Protection rating IP40
Insulation class insulation class I (protective earthing)
Certification, designation CE, UKCA

Material, Colour

connection compartment sheet steel, galvanised, coated, pure white, without terminals
Quantity 2 piece
blank cover PC/ABS, white
Quantity 1 piece
connector steel, galvanised, connector pre-assembled on trunking rail
Quantity 1 piece

Mounting

Mounting method, mounting location surface-mounted, to the Modario trunking rail

Dimensions, Weight

Length 299mm
Width 58mm
Height 43mm
Weight 0.7kg

Product type
infeed

Product name
Modario 31

Order No.
5TR91AFN0

Protection rating
IP40

Insulation class
insulation class I (protective earthing)

Certification, designation
CE, UKCA

connection compartment
sheet steel, galvanised, coated, pure white, without terminals

Quantity
2 piece

blank cover
PC/ABS, white

Quantity
1 piece

connector
steel, galvanised, connector pre-assembled on trunking rail

Quantity
1 piece

Mounting method, mounting location
surface-mounted, to the Modario trunking rail

Length
299mm

Width
58mm

Height
43mm

Weight
0.7kg
